A novel Ferroelectric FET (FeFET) structure to enable multi-level cell (MLC) storage using a cleaved gate (CG) is proposed for the first time. The CG-FeFET’s gate is divided into two gates by an insulator. The CG-FeFET is optimized based on well-calibrated TCAD models. We perform an extensive design space exploration by evaluating: 1) the impact of the length of separation oxide (LOX) between source side gate (G_S) and drain side gate (G_D); 2) whether reading from G_S or G_D is better; 3) the best placement of the insulator between the two gates comparing symmetric (LG_S= LG_D) vs. asymmetric (LG_S≠LG_D) structure.

IRPS 2022

Cleaved-Gate Ferroelectric FET for Reliable Multi-Level Cell Storage

poster
