Power Amplifier (PA) is a key component for embedded RF/mmWave on advanced CMOS technologies on the way to replace the III/V technologies. PA reliability has been a long-standing blocker for those applications. In this paper, a novel methodology is introduced based on an automated waveform analysis tool. Simulation aging results are compared with experimental silicon validation stress for a 28GHz high gain RF Power Amplifier (PA) and confirmed. Waveform analysis tool enables a deeper understanding of both continuous waveform (CW) with constant load and ruggedness test, as well as a new perspective about RF/mmWave circuit aging.

IRPS 2022

22FDX™ 5G 28GHz 20dBm Power Amplifier Constant Load and VSWR accelerated aging reliability

pa rf vswr

technical paper
