We investigate the impact of charge-trapping on ferroelectric (FE) switching and its influence on memory window (MW) and retention of FeFET. Fabricated FinFETs with ferroelectric gate stack were used to study defects properties (within HZO), trapping/FE-switching interplay, and dynamics. Starting from the electronic-assisted nucleation of FE domains, we investigated the interface charging and degradation, as well as their impact on the polarization compensation, MW and stabilization of the retention. Finally, a balance between those competing processes was analyzed and a retention model of FeFET (capturing behavior over device’s lifetime) was developed

IRPS 2022 Main Conference

Electron-assisted switching in FeFETs: MW dynamics – retention - trapping mechanisms and correlation

ferroelectric hfox

charge – trapping

fefet

degradation

retention

technical paper
