Design of reliable and high-performance RF power amplifiers in CMOS technologies is becoming more challenging due to the increasing reliability issues as we approach the scaling limit. To provide insight on hot-carrier injection (HCI) degradation at RF frequencies, this paper presents a comprehensive analysis to study this effect on different PA architectures based on their mission profile with a quasi-static approach. Sensitivity analysis on power amplifier RF performance is also discussed to offer a better understanding on the importance of accurate device and aging behavior modeling.

IRPS 2022 Main Conference

Comprehensive Analysis of RF Hot-Carrier Reliability Sensitivity and Design Explorations for 28GHz Power Amplifier Applications

rf reliability

hot-carrier degradation

power amplifier
