Resistive-switching random access memory (RRAM) is a promising technology for in-memory computing (IMC) to accelerate training and inference of deep neural networks (DNNs). This work presents the first physics-based statistical model describing (i) multilevel RRAM device program/verify (PV) algorithms by controlled set transition, (ii) the stochastic cycle-to-cycle (C2C) and device-to-device (D2D) variations within the array, and (iii) the impact of such imprecisions on the accuracy of DNN accelerators. The model can handle the full chain from RRAM materials/device parameters to the DNN performance, thus providing a valuable tool for device/circuit codesign of hardware DNN accelerators.

IRPS 2022

Statistical model of program/verify algorithms in resistive-switching memories for in-memory neural network accelerators

physical modeling

deep neural network accelerators

rram

technical paper

[![](https://assets.underline.io/uploads/markdown_image/1/image/f6b8cf9ecca2209dd3e0fcebe80a2915.png)](https://underline.io/events/282/reception)
[![](https://assets.underline.io/uploads/markdown_image/1/image/6b7a695cee2a4e6d07c0594938f00e41.png)](https://drive.google.com/file/d/1_V_fHL72jJWTmq-pUe-JJAR97y3dN5RX/view?usp=sharing)
[![](https://assets.underline.io/uploads/markdown_image/1/image/e787ff477f8d2b687fb0b54d83d35e11.png)](https://drive.google.com/drive/folders/1GAycr7pPrZG2ZzZP-geUL8vGWswjCB1N?usp=sharing)
[![](https://assets.underline.io/uploads/markdown_image/1/image/924447c4755e4e804db480b0504f6c13.png)](https://drive.google.com/drive/folders/1Mxu8R6jiCM_F1m_4pFdqgVKDfYaoTbtn?usp=sharing)
[![](https://assets.underline.io/uploads/markdown_image/1/image/7492fafcc0c623afe96fe15207855ed9.png)](https://www.irps.org/)




![](https://assets.underline.io/uploads/markdown_image/1/image/e1ce7df3286ab3a750966a5bf555716e.png)



**PROGRAM AT A GLANCE:**


![](https://assets.underline.io/uploads/markdown_image/1/image/fd55e96d31b53ac223d4e9b8d0186848.png)



**2022 IEEE International Reliability Physics Symposium has gone mobile!**

![](https://assets.underline.io/uploads/markdown_image/1/image/07a1cc9ee775657110a89eddbcc41388.jpg)




![](https://assets.underline.io/uploads/markdown_image/1/image/7a5e45b43771adf5ae4d3f97c1861ac1.png)
[![](https://assets.underline.io/uploads/markdown_image/1/image/a0cab03a0ec30cc71c71b5efec2ba603.png)](https://www.amd.com/en)[![](https://assets.underline.io/uploads/markdown_image/1/image/2921931b8aa0a090d96fd463670a0305.png)](https://www.cisco.com/)[![](https://assets.underline.io/uploads/markdown_image/1/image/d0cd3844560c9bdf8d4303b36d82dc69.png)](https://amazon.jobs/en/teams/lab126/)

![](https://assets.underline.io/uploads/markdown_image/1/image/c849d66095021f867725ff54b2c1f53e.png)
[![](https://assets.underline.io/uploads/markdown_image/1/image/8e648631fe7093b9613454de264d6745.png)](https://www.intel.com/content/www/us/en/homepage.html)[![](https://assets.underline.io/uploads/markdown_image/1/image/76970c33d96c19445badc60c21d890e8.png)](https://www.kioxia.com/en-emea/top.html)[![](https://assets.underline.io/uploads/markdown_image/1/image/546ecacb92116a8373a0cb2b3462dc1e.png)](https://about.google/)[![](https://assets.underline.io/uploads/markdown_image/1/image/91dca9e7aff5399ce0ea709d196c4f6a.png)](https://www.ibm.com/hr-en)[![](https://assets.underline.io/uploads/markdown_image/1/image/d1a1c95a5b0b551edea10f686f959c0d.png)](https://www.qualcomm.com/)[![](https://assets.underline.io/uploads/markdown_image/1/image/fa628a3cef7a5300e4ab59da0e0552fa.png)](https://www.samsung.com/hr/smartphones/galaxy-s22-ultra/?page=home)[![](https://assets.underline.io/uploads/markdown_image/1/image/948a0108c6b1b84e336b6f39bbc57fcf.png)](https://www.micron.com/)[![](https://assets.underline.io/uploads/markdown_image/1/image/74e631e654862d71a16d009817467e5c.png)](https://www.nvidia.com/en-eu/geforce/)[![](https://assets.underline.io/uploads/markdown_image/1/image/224a109509478bb0c4d361401ba65fae.png)](https://www.tsmc.com/english)[![](https://assets.underline.io/uploads/markdown_image/1/image/d70304be54ef831492c3cb99d8c1f3c7.png)](https://www.tel.com/)[![](https://assets.underline.io/uploads/markdown_image/1/image/7e60586f1c46e0157f2f452d4005fb54.png)](https://gf.com/)[![](https://assets.underline.io/uploads/markdown_image/1/image/e1c9bbe8892bbd4d89b81de064f31dfa.png)](https://www.appliedmaterials.com/)[![](https://assets.underline.io/uploads/markdown_image/1/image/dc19add30e3105172bdc93580e944dee.png)](https://www.ti.com/)[![](https://assets.underline.io/uploads/markdown_image/1/image/8e81ebc466ddd94f3fde7f3cdebb86c0.png)](https://www.skhynix.com/)[![](https://assets.underline.io/uploads/markdown_image/1/image/ccfa43258b058874e38e5903f79e63bc.png)](https://www.st.com/content/st_com/en.html)


![](https://assets.underline.io/uploads/markdown_image/1/image/e4c5690a7016a468518eeab6ed0f7e56.png)
[![](https://assets.underline.io/uploads/markdown_image/1/image/c33da95f78e91c05d51b787f02a1af01.png)](https://www.infineon.com/)
![](https://assets.underline.io/uploads/markdown_image/1/image/e708450912afd1718c5af9e9dfd70d3f.png)
[![](https://assets.underline.io/uploads/markdown_image/1/image/ffd1b2531ec1531672693a786e5a1b37.png)](https://eds.ieee.org/)[![](https://assets.underline.io/uploads/markdown_image/1/image/0a58c969093f21f088af904b1cb4e112.png)](https://rs.ieee.org/)

IRPS provides numerous opportunities for attendees to increase their knowledge and understanding of all aspects of microelectronics reliability. It is also an outstanding chance to meet and network with reliability colleagues from around the world.

The leakage current and threshold voltage instability of NO nitrided SiC(1-100) m-face MOS devices was intensively studied. Nitridation at a typical temperature of 1250°C was found to reduce the onset field of Fowler-Nordheim tunneling current by about 1 MVcm-1. Moreover, systematic positive and negative voltage stress measurements revealed that the nitrided m-face MOS devices exhibit much larger threshold voltage shifts compared to a reference Si-face device. Despite the improvement in the MOS interface quality by NO nitridation, our results clearly indicate the drawbacks of nitridation for m-face MOS devices in terms of reliability.

Investigation of reliability of NO nitrided SiC(1-100) MOS devices

Threshold voltage instability in 4H-SiC MOSFETs was investigated by means of combined cyclic gate bias stress measurements and single gate bias point measurements. This allowed to separate the contributions of interface states (Nit) and near interface oxide traps (NIOTs) in the nitridated deposited gate oxides. Nanoscale chemical analyses by electron energy loss spectroscopy allowed to correlate these trapping states to the presence of a sub-stoichiometric silicon oxide (~1 nm) and carbon-related defects (&lt;1 nm) on different SiO2/4H-SiC interfaces In particular, the sub-stoichiometric silicon oxide was correlated to the interface states and the carbon-related defects have been correlated to the NIOTs.

SiO2/4H-SiC interfacial chemistry as origin of the threshold voltage instability in power MOSFETs

The circuit functionalities of Complementary Metal-Oxide-Semiconductor (CMOS) devices on 4H-SiC for digital and analog circuit applications beyond 200˚C have been extensively studied, however, the reliability of the devices on SiC needs to be demonstrated due to the traps at/near the dielectric interface. In this report, the reliability of n- and p- Metal Oxide Semiconductor Field Effect Transistors (MOSFETs) has been studied on three different gate oxide conditions – thick thermally grown, ultrathin thermal + thick CVD oxide and ultrathin thermal + thin CVD oxide in terms of their bias temperature instability (BTI) measurement. The MOSFETs were stressed at various constant bias voltages at 150˚C and up to 105s. The threshold voltage shift due to positive bias on n-MOSFET is &lt;0.5V after 105s at +25Vwhile p-MOSFET shows a larger shift of -1.9V shift after 105s at -25V and 150˚C for ultrathin + thick CVD oxide. The report also establishes improvement in reliability of p-MOSFETs with ultrathin + CVD oxides over thermally grown oxides.

Bias Temperature Instability on SiC n- and p-Channel MOSFETs for High Temperature CMOS Applications

In-memory computing (IMC) with memory arrays allows reducing the time and energy consumption for matrix vector multiplication (MVM) for artificial neural networks (ANN) inference. However, the IMC accuracy is affected by nonidealities, such as program/read variations of device conductance and the parasitic voltage (IR) drop along the wires, whose impact quickly increases when increasing the array size. This work presents new IMC circuit architectures for mitigating both variations and IR drop at the same time. The  new schemes allow for improving the accuracy of an ANN from 72.7% to 94.9%, compared to a software accuracy of 96.9%, at the expense of an increase of the memory array area.

Mitigating read-program variation and IR drop by circuit architecture in RRAM-based neural network accelerators

In this work, analog and RTN performance of transistors operating in low current conditions were investigated. It is proven that in subthreshold regime the RTN signal is driven by defects located at the STI edges. Reducing the amount of electrical impurities situated at the device periphery lead to evident RTN improvement without significant change in targeting or reliability, and reduce the noise sensitivity to temperature and body bias. Empirical correlation between RTN and intrinsic gain was also reported, which can be used for fast inline process monitoring of defects located in the STI edges.

Impact of Electrical Defects located at Transistor Periphery on Analog and RTN Device Performance

In this paper, we present a detailed study of negative bias temperature instability (NBTI) and Time dependent dielectric breakdown (TDDB) reliability in p-type stacked gate- all -around (GAA) Nanosheet (NS) transistors with SiGe channel and compared with NS Si pFETs. Robust NBTI and TDDB reliability performance is achieved on SiGe gate-all-around NS.


SiGe Gate-All-around Nanosheet Reliability

The issues related to the failure analysis of 4H-SiC PowerMOSFET failed at EWS (Electrical Wafer Sorting) such as the channel leakage current is investigated. In particular, EWS is carried out in the namely defect free wafers areas monitored at several inline levels. This paper reports on the electrical based methods used to spot macroscopic defects even if they are invisible at optical wafer inspections. In particular, the current separation technique on source and gate terminals allowed to reduce the number of  candidate samples to be investigated

Failure analysis addressing method of optically undetected defectivity on 4H-SiC PowerMOSFET epitaxial layer

This work presents the influence of SiC epitaxial wafer quality on yield of SiC-DMOSFETs. Various wafer quality indicators were estimated by an integrated wafer quality evaluation system. SiC-DMOSFETs were fabricated on six 100 mm 4H-SiC epitaxial wafers. We show that the yield of SiC-DMOSFETs is related to threading screw dislocation density, defect density and bunched-steps length density evaluated by wafer inspection apparatuses.

Influence of SiC epitaxial wafer quality on yield of 1.2kV SiC-DMOSFETs

Several designs of 1.2kV-rated 4H-SiC PiN diodes and Junction Barrier Schottky (JBS) diodes have been successfully fabricated with various P+ implantation conditions resulting in different junction profiles. P+ regions were implanted at both room temperature and elevated temperature in order to monitor the generation of Basal Plane Dislocations (BPDs) and study their impact on device long term reliability. It was found that, when the dose in the deeper portion of the junction (implemented by high energy) is well suppressed, static and long-term reliability performances of room temperature implanted devices can be maintained similar to those of high temperature implanted devices.

Static Performance and Reliability of 4H-SiC Diodes with P+ Regions Formed by Various Profiles and Temperatures

Resistive random-access memory (RRAM)-based in-memory computing (IMC) recently became a promising paradigm for efficient deep neural network acceleration. The multi-bit RRAM arrays provide dense storage and high throughput, whereas the physical non-ideality of the RRAM devices impairs the retention characteristics of the resistive cells, leading to accuracy degradation. On the algorithm side, various hardware-aware compression algorithms have been proposed to accelerate the computation of deep neural networks (DNNs) computation. However, most recent works individually consider the "model compression" and "hardware robustness". The impact of the RRAM non-ideality for the sparse model is still under-explored. In this work, we present a novel temperature-resilient RRAM-based IMC scheme for reliable DNN inference hardware. Based on the measurement from a 90nm RRAM prototype chip, we first explore the robustness of the sparse model under the different operating temperatures (25°Cto 85°C). On top of that, we propose a novel robustness-aware pruning algorithm, then further enhance the model robustness with a novel sparsity-aware noise-injected fine-tuning. The proposed scheme achieves &gt;92% CIFAR-10 inference accuracy after one-day operation, which is &gt;37% higher than the state-of-art method.
