The circuit functionalities of Complementary Metal-Oxide-Semiconductor (CMOS) devices on 4H-SiC for digital and analog circuit applications beyond 200˚C have been extensively studied, however, the reliability of the devices on SiC needs to be demonstrated due to the traps at/near the dielectric interface. In this report, the reliability of n- and p- Metal Oxide Semiconductor Field Effect Transistors (MOSFETs) has been studied on three different gate oxide conditions – thick thermally grown, ultrathin thermal + thick CVD oxide and ultrathin thermal + thin CVD oxide in terms of their bias temperature instability (BTI) measurement. The MOSFETs were stressed at various constant bias voltages at 150˚C and up to 105s. The threshold voltage shift due to positive bias on n-MOSFET is &amp;lt;0.5V after 105s at +25Vwhile p-MOSFET shows a larger shift of -1.9V shift after 105s at -25V and 150˚C for ultrathin + thick CVD oxide. The report also establishes improvement in reliability of p-MOSFETs with ultrathin + CVD oxides over thermally grown oxides.

IRPS 2022 Main Conference

Bias Temperature Instability on SiC n- and p-Channel MOSFETs for High Temperature CMOS Applications

transconductance

threshold voltage

field-effect mobility

cmos

reliability

Download the proceedings [here](https://underline.io/events/372/lounge)


 The IEEE Workshop on Wide Bandgap Power Devices & Applications (WiPDA) provides a forum for device scientists, circuit designers, & application engineers from the Power Electronics & Electron Devices Societies to share technology updates, research findings, experience & potential applications.

 **Topics of interest**
* Heteroepitaxial & Bulk Materials Growth
* Gate Dielectrics & Surface Passivation
* Device Structures & Fabrication Techniques
* Device Characterization & Modeling
* Very-High Efficiency Or Compact Converters
* Safe Operating Areas Of Wide Bandgap Devices, including Short Circuit, Spike, &Transient Tolerance
* Harsh Environment (High Temperature) Operation & Reliability
* Packaging Power Modules & ICs
* Gate Drive & Other Auxiliary Circuits
* High-Performance Passive Components
* Hard-Switched & Soft-Switched Application Analysis
* Applications in Renewable Energy & Energy Storage, Transportation, Industrial Drives, Grid Power Systems, Space and Aerospace
* Wide Bandgap System Design Philosophies & Strategies
* Radio Frequency (RF) GaN
* Technology Roadmap of Wide Bandgap Including Devices, Applications and Packaging

You must register to attend this event. If you haven't done so already, please use the link below to register for the event. All registered attendees will have access to the event site on November 4th.

Registration Is Required

IEEE WiPDA 2022

The IEEE Workshop on Wide Bandgap Power Devices & Applications (WiPDA) provides a forum for device scientists, circuit designers, & application engineers from the Power Electronics & Electron Devices Societies to share technology updates, research findings, experience & potential applications.

The circuit functionalities of Complementary Metal-Oxide-Semiconductor (CMOS) devices on 4H-SiC for digital and analog circuit applications beyond 200˚C have been extensively studied, however, the reliability of the devices on SiC needs to be demonstrated due to the traps at/near the dielectric interface. In this report, the reliability of n- and p- Metal Oxide Semiconductor Field Effect Transistors (MOSFETs) has been studied on three different gate oxide conditions – thick thermally grown, ultrathin thermal + thick CVD oxide and ultrathin thermal + thin CVD oxide in terms of their bias temperature instability (BTI) measurement. The MOSFETs were stressed at various constant bias voltages at 150˚C and up to 105s. The threshold voltage shift due to positive bias on n-MOSFET is &lt;0.5V after 105s at +25Vwhile p-MOSFET shows a larger shift of -1.9V shift after 105s at -25V and 150˚C for ultrathin + thick CVD oxide. The report also establishes improvement in reliability of p-MOSFETs with ultrathin + CVD oxides over thermally grown oxides.

technical paper

#### Welcome to the 60th IEEE International Reliability Physics Symposium (IRPS)!

[![](https://assets.underline.io/uploads/markdown_image/1/image/f6b8cf9ecca2209dd3e0fcebe80a2915.png)](https://underline.io/events/282/reception) [![](https://assets.underline.io/uploads/markdown_image/1/image/e787ff477f8d2b687fb0b54d83d35e11.png)](https://drive.google.com/drive/folders/1GAycr7pPrZG2ZzZP-geUL8vGWswjCB1N?usp=sharing) [![](https://assets.underline.io/uploads/markdown_image/1/image/7492fafcc0c623afe96fe15207855ed9.png)](https://www.irps.org/)


**General Chair Welcome Message**

Welcome to IRPS 2022! When the IRPS Management Committee began making plans for Dallas, we recognized the strong desire by the reliability physics community to return to a face-to-face symposium that we last had in Monterey in 2019. But as time progressed, we recognized that travel restrictions were not being lifted as rapidly as we anticipated. Rather than leave out those of you who could not attend in person, we adopted a hybrid format allowing for both remote attendance and remote presentations. This is a first for IRPS and I am confident it will be a success for all.

With this new hybrid format, the symposium will return to the original five-day format with Tutorials and Year in Review on the first two days. The Technical Program, Keynote Talks, Workshops and Poster session will be held on the following three days. All of these (except Workshops and Posters) will be available via real-time streaming in the US Central Time zone with virtual attendees having Q&A access to the presenters. For those virtual attendees who cannot watch the live presentations, the material will be available on demand to all attendees for a month after the symposium with the ability to communicate with the authors.

In 2020, we were planning on co-hosting the International ESD Workshop (IEW) ESD workshop when the COVID-19 pandemic hit. For 2022, IEW will be seamlessly embedded into the IRPS Program and will sponsor three tutorials, an invited talk, two technical sessions and two evening workshops focused on ESD and latch-up. And we continue our
collaboration with our sister conference, European Symposium on Reliability of Electron Devices Failure Physics and Analysis (ESREF) by hosting their Best Paper and the International Integrated Reliability Workshop (IIRW) by hosting their Best Student Paper.

Our primary objective is to maintain the symposium’s leadership role in the reliability physics of microelectronic devices by attracting leading researchers to present their work and providing attendees the best place to access this information. With all the buzz in the media about whether Moore’s Law has hit its limit, IRPS has been promoting expertise developed in silicon-based reliability over the past sixty years and expanding into new material areas. This year, eight of the technical sessions are devoted to reliability in topics outside of traditional silicon, including wide bandgap GaN/SiC, emerging memory and neuromorphic computing. I hope our ability to draw these communities together will accelerate the cross-fertilization of ideas.

The Technical Program consists of four keynote speakers, twenty-three invited speakers and eighty-seven oral presentations organized in thirty technical sessions on eighteen reliability topics. Over two evenings, there will be ten Workshops and sixty-six Poster presentations that are designed to allow in person attendees and experts to interact
with one another. With eighteen tutorials covering topics ranging from fundamental transistor and memory reliability all the way up to automotive and complex system-level reliability, this year’s symposium provides an excellent learning opportunity for engineers and scientists new to reliability as well as experienced individuals wanting to explore new
areas. The Year in Review, which serves as a summary of research in the past year, will cover 3D packaging, emerging memory and aging aware circuit designs.

Finally, I would like to express my extreme gratitude to our patrons and exhibitors, whose support makes IRPS possible.
And to all of you, our in person and virtual attendees, for supporting this symposium for sixty years!

**Charles W. Slayman, General Chair**
**of 2022 IRPS Management Committee**

**About IRPS**

The IEEE International Reliability Physics Symposium (IRPS) is the premiere conference for engineers and scientists to present new and original work in the area of microelectronics reliability. Drawing participants from the United States, Europe, Asia, and all parts of the world, IRPS seeks to understand the reliability of semiconductor devices, integrated circuits, and microelectronic assemblies through an improved understanding of both the physics of failure as well as the application environment. IRPS provides numerous opportunities for attendees to increase their knowledge and understanding of all aspects of microelectronics reliability, and to meet and network with reliability colleagues from around the world.

Please log in to explore this event. You need to log in with the email address you registered with. Access credentials have been sent to your email.

Please log in to explore this event.

Registration for this conference has now closed. We appreciate your interest and hope to welcome you at a future event. If you’d like to hear about similar upcoming events, please check our website or join our mailing list.

Registration for this conference has now closed.

IRPS provides numerous opportunities for attendees to increase their knowledge and understanding of all aspects of microelectronics reliability. It is also an outstanding chance to meet and network with reliability colleagues from around the world.

Bias Temperature Instability refers to the widely known shift of the threshold voltage of metal-oxide-semiconductor field-effect transistors upon changes of gate bias and is typically measured at room temperature or above. The shift of the threshold voltage is caused by trapping/detrapping of charges in pre-existing defects located close to the semiconductor-insulator interface as well as the generation of new defects. Particularly silicon carbide transistors show a pronounced short-term trapping/detrapping behavior, which leads to threshold voltage variations already well below the microsecond time frame after gate bias changes. The physics of involved charge transfer reactions has been accurately described by non-radiative multiphonon transitions. We present evidence that in SiC devices radiative charge transitions are also present in a Bias Temperature Instability experiment, once the transistor is switched between accumulation and inversion or vice versa. Furthermore, we present a field-effect based pump-probe measurement that allows us to correlate the number of emitted photons after microsecond gate pulses to the threshold voltage recovery.

Optical Emission Correlated to Bias Temperature Instability in SiC MOSFETs

The leakage current and threshold voltage instability of NO nitrided SiC(1-100) m-face MOS devices was intensively studied. Nitridation at a typical temperature of 1250°C was found to reduce the onset field of Fowler-Nordheim tunneling current by about 1 MVcm-1. Moreover, systematic positive and negative voltage stress measurements revealed that the nitrided m-face MOS devices exhibit much larger threshold voltage shifts compared to a reference Si-face device. Despite the improvement in the MOS interface quality by NO nitridation, our results clearly indicate the drawbacks of nitridation for m-face MOS devices in terms of reliability.

Investigation of reliability of NO nitrided SiC(1-100) MOS devices

Threshold voltage instability in 4H-SiC MOSFETs was investigated by means of combined cyclic gate bias stress measurements and single gate bias point measurements. This allowed to separate the contributions of interface states (Nit) and near interface oxide traps (NIOTs) in the nitridated deposited gate oxides. Nanoscale chemical analyses by electron energy loss spectroscopy allowed to correlate these trapping states to the presence of a sub-stoichiometric silicon oxide (~1 nm) and carbon-related defects (&lt;1 nm) on different SiO2/4H-SiC interfaces In particular, the sub-stoichiometric silicon oxide was correlated to the interface states and the carbon-related defects have been correlated to the NIOTs.

SiO2/4H-SiC interfacial chemistry as origin of the threshold voltage instability in power MOSFETs

Time and drain bias dependence of HCD under peak ISUB (VG ~ VD/2) stress are modeled. Published n-MOSFET data for different LCH (2.0µm to 37nm), TOX (35nm to 1.85nm), type of junction (HDD, LDD/HDD, SDE/HDD) and stress VD (8V to 1.6V) are analyzed. A compact model is used to model the time kinetics and to explain its difference (i.e., power law or non-power law) in devices having different types of junctions. The dominant energy model is used for VD dependence, and the model parameters are obtained with scaling. The time kinetics and VD dependence are also modeled using TCAD simulations.

Modeling Time and Bias Dependence of Classical HCD Mechanism (Peak ISUB Stress) in n-MOSFETs

Ultrafast measurements (with 10μs delay) are done to characterize the Negative Bias Temperature Instability (NBTI) and Hot Carrier Degradation (HCD) induced threshold voltage shift (ΔVT) in p-channel Gate All Around Stacked Nano-Sheet (GAA-SNS) Field Effect Transistors (FETs). A model framework is proposed to estimate the measured ΔVT time kinetics during and after NBTI and HCD stress. The BTI Analysis Tool (BAT) framework is calibrated using pure NBTI data (drain bias, VD, at 0V) across gate bias (VG) and temperature (T) and is subsequently used to estimate the underlying NBTI contribution during and after HCD stress under full VG/VD space in the presence of Self-Heating (SH) effect. The pure HCD kinetics is calculated using an empirical model, with VG, VD and T dependence incorporated via a vertical field enhanced dominant energy model.

Decoupling of NBTI and Pure HCD Contributions in p-GAA SNS FETs Under Mixed VG/VD Stress

The suitability of a 12nm FinFET LDMOS offering toward a broad range of applications has been demonstrated with respect to key reliability aspects. The impact of well-known degradation mechanisms, such as conductive and non-conductive Hot Carrier Injection and the off-state Time Dependent Dielectric Breakdown is discussed. The impact of process and design optimization with respect to reliability and time zero performance is addressed as well.

Optimized LDMOS Offering for Power Management and RF Applications

The effect of reverse body bias on hot carrier (HCI) reliability is studied in details at CHE (channel hot carrier) and DAHC (drain avalanche hot carrier) stress conditions in advanced standard gate n-channel FinFET transistors.  HCI degradation is found to be independent of reverse body bias, when the body bias, Vb is low (0V ~ -1V).  However, HCI starts to aggravate at further negative Vb (-1V ~ -2V) for both CHE and DAHC conditions, showing strong dependence on the transverse electric field. The physical mechanism is attributed to the increased e-h pair generations, enhancing electron trapping in the gate oxide. This study addresses a key reliability constraint for circuit designers while designing tuned body bias circuitry

Reverse Body Bias Dependence of HCI Reliability in Advanced FinFET

In this work, analog and RTN performance of transistors operating in low current conditions were investigated. It is proven that in subthreshold regime the RTN signal is driven by defects located at the STI edges. Reducing the amount of electrical impurities situated at the device periphery lead to evident RTN improvement without significant change in targeting or reliability, and reduce the noise sensitivity to temperature and body bias. Empirical correlation between RTN and intrinsic gain was also reported, which can be used for fast inline process monitoring of defects located in the STI edges.

Impact of Electrical Defects located at Transistor Periphery on Analog and RTN Device Performance

In this paper, we present a detailed study of negative bias temperature instability (NBTI) and Time dependent dielectric breakdown (TDDB) reliability in p-type stacked gate- all -around (GAA) Nanosheet (NS) transistors with SiGe channel and compared with NS Si pFETs. Robust NBTI and TDDB reliability performance is achieved on SiGe gate-all-around NS.


SiGe Gate-All-around Nanosheet Reliability

Assessment of transistor degradation in analog circuits during aging effect is challenging due to wide spread of operating points. This paper presents our proposed characterization approaches of full ID-VG
degradation for large and nanoscale devices respectively. Threshold voltage shift and mobility degradation in large devices can be extracted simultaneously with fast measurement speed (tm=3us). Based on this, full ID-VG
degradation can be assessed intuitively. Impacts of individual defects on full ID-VG degradation in nanoscale devices are characterized with the proposed approach with high resolution. Thus this paper provides a helpful solution to the characterization of device degradation in analog circuits.
