After an introduction to the npSCOPE instrument and its capabilities we will introduce the new STIM detector and present first results obtained with it on single and polycrystalline samples as well biological specimen. The latter will focus on different kinds of nanoparticle samples relevant in the field of nano-toxicology.

EIPBN 2021

 Scanning Transmission Ion Micrsocopy in the Helium Ion Microscope for nanoparticle research

channeling

helium ion microscopy

focused ion beam

sims

nanoparticles

The International Conference on Electron, Ion and Photon Beam Technology and Nanofabrication (EIPBN), affectionately known as "3-Beams," is the premier gathering of scientists and engineers who are dedicated to electron, ion and photon lithography, imaging, and analysis; atomically precise fabrication; nanofabrication process technologies and related emerging technologies; and their applications in a broad spectrum of fields. In its 64th meeting, researchers from academia, government laboratories, and industry from around the world meet to present and discuss recent and future trends in these technologies.
