We reveal, for the first time, a comprehensive physical insight into high-field electrical breakdown in two-dimensional (2D) transition metal dichalcogenide (TMD) FETs. Electrical, optical, and electro-optic properties of 2D TMD FETs are extensively analyzed in the FETs operated in the non-destructive breakdown regime. Careful investigations reveal that hot carrier electroluminescence (EL) observed in the devices operated at the verge of breakdown can have two distinct origins.

IRPS 2024 Main Conference

Hot Carrier Dynamics and Electrical Breakdown Analysis in 2D Transition Metal Dichalcogenide FETs
