We report a non-monotonical temperature dependence of hot carrier injection (HCI) degradation for 14 nm Si FinFETs operated at low temperature (LT). An HCI model including multiple-particle single-particle and oxide traps was proposed to separate the effects from different traps. As stress time increases, the dominant traps switched from single-particle traps to oxide traps, and as temperature reduces, oxide traps and single-particle traps will make more contributions to the HCI degradation.

IRPS 2024 Main Conference

Low Temperature Characterization and Modeling of Hot Carrier Injection in 14 nm Si FinFET

poster
