In this paper,we have developed a new convolution-based methodology to estimate the dynamic time-evolutionary degradation of pixel circuits in display applications. For the first time, we have enabled real-time observation of the threshold voltage changes over time in key driving TFTs under different bias conditions in transient simulations of pixel circuits. Additionally, we introduce an optimized 9T2C pixel compensation circuit,which is an approximately 50% improvement over the 0.73μA observed in the 7T1C configuration.

IRPS 2024 Main Conference

Convolution-Based Vth Shift Prediction and the New 9T2C Pixel Circuit in LTPS TFT AMOLED

poster
