Sentaurus TCAD is enabled to simulate parametric shift due to BTI and HCD in p-andn- GAASNSFETs.The framework is calibrated using ultra-fast measured BTI data at different VG andT, and HCD data at different VG and VD during and after stress.The isolated BTI and intrinsic HCD contributions are used in a cycle-by-cycle circuit simulation framework to determine Ring Oscillator(RO) degradation at various VDD, Tand Dynamic Voltage and Frequency Scaling(DVFS) conditions.The End-of-Life(EOL) device and RO degradation are compared.

IRPS 2024 Main Conference

A TCAD to SPICE Framework for Isolation of BTI and HCD in GAA-SNS FETs and to Estimate Impact on RO Under Normal and Overclocking Conditions

poster
