As ESD design window shrinks, even GOX degradation before hard breakdown during component-level CDM qualification can cause reliability issues such as soft-failures. This study analyzes CDM-induced bias temperature instability (BTI)-like degradation and models threshold voltage (Vth) shift using a very-fast transmission line pulse (VF-TLP), generally proposed for CDM evaluation. Finally, the Vth shift model considering statistical variation is presented. This model can be a guideline to prevent CDM-induced GOX degradation at the early design stage.

IRPS 2024 Main Conference

An Analysis of CDM-induced BTI-like Degradation using VF-TLP in Advanced FinFET Technology

very fast transmission line pulse(vf-tlp)

bias temperature instability(bti)

charged device model(cdm)

electrostatic discharge(esd)

technical paper
