In this work, we demonstrate vertically stacked multilayer atomic-layer-deposited sub-1nm In2O3 field-effect transistors (FETs) with surrounding gate in a back-end-of-line (BEOL) compatible low-temperature fabrication process. Multilayer FETs with number of In2O3 layers up to 4 and 1.2 nm-thick HfO2 between each individual layer are fabricated. An enhancement of on-state current (ION) from 183 μA in single layer In2O3 FET to 339 μA in 4 layer device with on/off ratio of 3.4×10^4 is achieved.

DRC 2022

Vertically Stacked Multilayer Atomic-Layer-Deposited Sub-1-Nanometer In2O3 Field-Effect Transistors with BEOL Compatibility

vertically stacked field-effect-transistors

indium oxide

atomic layer deposition
