For p-type Cu2O thin film transistors (TFTs), high contact resistance is one of the critical issues that limit field effect mobility. Thus, to alleviate the contact resistance issue, in this work, we for the first time demonstrated Cu2O TFTs with nitrogen-doped Cu2O S/D interlayer. We observe a reduced contact resistance and improved field effect mobility when the N:Cu2O S/D interlayer is used.

DRC 2022

N:Cu2O S/D for low contact resistance p-type Cu2O thin film transistor

cu2o

thin film transistor

contact resistance
