We report for the first time that a single sub-nanosecond pulse can fully switch HfO2-based FeFET. We also study the polarization switching kinetics across 11 orders of magnitude in time and find an extremely steep time-voltage relation, which is captured by the domain nucleation model across this wide range of pulse widths

DRC 2022

Sub-Nanosecond Switching of Si:HfO2 Ferroelectric Field-Effect Transistor

sub-nanosecond switching

high-speed memory

ferroelectric field effect transistor (fefet)

neuromorphic devices

hfo2

non-volatile memory
