**Please read the paper on the following link:**

https://1worldcontent.com/ess/9056.pdf

**Abstract:**

RRAM-based compute-in-memory (CIM) has shown great potentials for deep neural network inference. Prior works generally used off-chip write-verify for tightening resistance distributions and off-chip ADC references to fine-tune partial sum quantization, which may be unsuitable for practical applications. This work presents an RRAM-CIM macro that features 1) on-chip write-verify to speed up initial weight programming and periodically refresh cells to compensate for resistance drift, and 2) on-chip ADC reference generation that provides column-wise tunability to mitigate ADC offsets to guarantee CIFAR-10 accuracy of &gt;90%. The design is taped-out in TSMC N40 RRAM process, and achieves 36.4TOPS/W on VGG-8 network.

ESSCIRC ESSDERC 2021

A 40nm RRAM Compute-in-Memory Macro Featuring On-Chip Write-Verify and Offset-Cancelling ADC References

adc reference generation

write-verify

compute-in-memory

rram

non-volatile memory
