Simulations based on first-principle modeling of material structural features determining electrical properties of a CNT memory cell allow to identify a range of operation conditions delivering desirable device characteristics. This approach designates the path for optimization of the CNT memory device structure to meet the performance requirements.

IRPS 2022

Combining measurements and modeling/simulations analysis to assess carbon nanotube memory cell characteristics
