This work presents a high-voltage-tolerant (HVT) supply clamp for ESD protection, in which the current drive of the clamp during an ESD event is maximized without compromising reliability during normal operation. Similar to prior HVT clamps, ESD current shunting is provided by 3 cascoded NFETs; however, the trigger circuit is improved. The design is implemented in a 45-nm SOI CMOS technology and the clamp devices are sized for a 2-kV HBM protection level. As evidenced by TLP and VFTLP measurements, the new clamp offers 50% reduction of on-resistance and 0.6 V lower turn-on voltage, relative to the prior art.

IRPS 2022

A High Voltage Tolerant Supply Clamp for ESD Protection in a 45-nm SOI Technology

supply clamp

cmos

technical paper
