In-memory computing (IMC) with memory arrays allows reducing the time and energy consumption for matrix vector multiplication (MVM) for artificial neural networks (ANN) inference. However, the IMC accuracy is affected by nonidealities, such as program/read variations of device conductance and the parasitic voltage (IR) drop along the wires, whose impact quickly increases when increasing the array size. This work presents new IMC circuit architectures for mitigating both variations and IR drop at the same time. The  new schemes allow for improving the accuracy of an ANN from 72.7% to 94.9%, compared to a software accuracy of 96.9%, at the expense of an increase of the memory array area.

IRPS 2022

Mitigating read-program variation and IR drop by circuit architecture in RRAM-based neural network accelerators

neural network accelerators

crosspoint array

in-memory computing

crossbar array

emerging memories

technical paper
