Since 1973, Earliest Deadline First (EDF) uniprocessor scheduling has been known to be superior to its Rate Monotonic (Fixed-Priority, FPS) counterpart. Such superiority manifested in optimality, the capacity of EDF to feasibly sustain full utilization, which FPS can only achieve in certain favorable circumstances. In 2005, further research results argued that EDF&#39;s superiority would also extend to finer-grained performance indicators, such as preemption count, release and response-time jitter, resilience to transient overload. Recent work allowed EDF uniprocessor scheduling to be used in place of default FPS in Ada Ravenscar systems with unchanged application code: this development provides an interesting and practical avenue for empirical EDF-to-RM performance comparisons in an especially lean and efficient embedded setting. We leveraged that opportunity to develop a toolbox that enables quantitative comparison of EDF-to-RM uniprocessor scheduling with lightweight run-time tracing and offline analytic. In this work we present that toolbox and illustrate results we obtained with it, which shed new light on the presumed superiority of EDF to RM.

AEiC 2021 - 25th Ada-Europe International Conference on Reliable Software Technologies

Removing bias from the judgment day: A Ravenscar-based toolbox for quantitative comparison of EDF-to-RM uniprocessor scheduling

[![](https://assets.underline.io/uploads/markdown_image/1/image/359fc42963be9dbef8d1acac451d7c3e.png)](https://www.ada-europe.org/conference2021)

### Welcome Message from our Co-Chairs

Through this message, we want to give you our warmest welcome to the 25th Ada-Europe International Conference on Reliable Software Technologies (AEiC 2021). The special circumstances we all go through have made the conference a virtual event. Nonetheless, this will allow us to take advantage of the benefits of this format by using the Underline.io platform that allows remote participation of speakers and attendees and a virtual exhibition.
The platform will also provide a virtual space through Gather.Town to facilitate social interaction among participants, which, in addition to presenting state of the art research results, is one of the most important goals of a conference. This platform will hold various social events together with breaks and a poster session.

The conference schedule includes a four-day program and exhibition from Monday to Thursday, with parallel tutorials on Monday, and keynotes, technical sessions and a Work-in-Progress session on the remaining three days. The technical sessions include the presentations of 13 journal-track papers, 5 industrial presentations and 6 invited talks on leading topics on reliable software technologies. The program will be completed with three outstanding keynotes that will delight the participants.

The main conference activities will be from 13:00 to 18:00 Central European Summer Time (CEST) to allow participants from America to Central Asia to attend to the conference sessions. Virtual social events are scheduled at the beginning and the end of each day. We encourage you to participate in these activities as well as visiting the exhibition. We look forward to meeting you virtually in June 2021!

**J. Javier Gutiérrez and Mario Aldea Rivas**
 // AEiC 2021 Program Co-Chairs

![](https://assets.underline.io/uploads/markdown_image/1/image/609207a715bd5da2ea56e9a32b0d17ae.png)
![](https://assets.underline.io/uploads/markdown_image/1/image/5bd0a9396b4c6903d0ca52825b81fbe6.png)




Please register with AEiC to be able to enter the conference on Underline.io. If you have already registered, please login to Underline.io to be able to see full conference content. In case you do not have an Underline account, please create one. Thank you

Please login to your Underline account

Since 1973, Earliest Deadline First (EDF) uniprocessor scheduling has been known to be superior to its Rate Monotonic (Fixed-Priority, FPS) counterpart. Such superiority manifested in optimality, the capacity of EDF to feasibly sustain full utilization, which FPS can only achieve in certain favorable circumstances. In 2005, further research results argued that EDF's superiority would also extend to finer-grained performance indicators, such as preemption count, release and response-time jitter, resilience to transient overload. Recent work allowed EDF uniprocessor scheduling to be used in place of default FPS in Ada Ravenscar systems with unchanged application code: this development provides an interesting and practical avenue for empirical EDF-to-RM performance comparisons in an especially lean and efficient embedded setting. We leveraged that opportunity to develop a toolbox that enables quantitative comparison of EDF-to-RM uniprocessor scheduling with lightweight run-time tracing and offline analytic. In this work we present that toolbox and illustrate results we obtained with it, which shed new light on the presumed superiority of EDF to RM.
