Label-free optical observation of transparent nano-objects is challenging. We present PlAsmonic NanO-apeRture lAbel-free iMAging (PANORAMA) to image, size, count and monitor single nanoparticle with a size limit approaching sub-10 nm. Molecular imaging is envisioned with functionalized substrates for single nanoparticle analysis for extracellular vesicles (e.g., exosomes) and pathogens (e.g., viruses).

EIPBN 2021

A new label-free plasmonic imaging technique for quantitative analysis of transparent nanoscale objects approaching molecular size
