We use focused ion beams to create specific defects on suspended 2D materials (graphene, MoS2, WSe2). We study the extent to which the defects act as nucleation sites for Au, and tune deposition conditions and surface cleanliness to facilitate self-assembly of specific nanoisland shapes.

EIPBN 2021

Focused Ion Beam Patterning for Defect-Mediated Nucleation on 2D van der Waals Materials

nucleation

defect engineering

2d materials

focused ion beam

transmission electron microscopy

The International Conference on Electron, Ion and Photon Beam Technology and Nanofabrication (EIPBN), affectionately known as "3-Beams," is the premier gathering of scientists and engineers who are dedicated to electron, ion and photon lithography, imaging, and analysis; atomically precise fabrication; nanofabrication process technologies and related emerging technologies; and their applications in a broad spectrum of fields. In its 64th meeting, researchers from academia, government laboratories, and industry from around the world meet to present and discuss recent and future trends in these technologies.
