Ultrahigh aspect-ratio structures are important for x-ray optics, energy storage, and sensors. Atomic layer deposition with nucleation and growth enhancement was developed to coat nanoporous silicon microstructures with aspect ratios up to 500:1, an order of magnitude higher than before. Devices prepared with these structures provide integrated on-chip energy storage.

EIPBN 2021

Ultrahigh Aspect Ratio Silicon Nanoporous Microstructures Coated Using ALD with Nucleation Enhancement for Energy Storage and Other Applications

mace

platinum


![](https://assets.underline.io/uploads/markdown_image/1/image/2e10c515564e9ec3287ee4c664011c20.png)

The energy cost of storing and moving data is enormous, and is growing at such a rapid pace that within a few years the power demand may overwhelm some developed nations. Non-volatile memory (NVM) and neuromorphic computing are enabling critical advances in this area, but there are many scientific and technological challenges. This conference will cover the materials challenges of different memory technologies, from the fundamental processes and mechanisms, to industry perspectives on materials specifications and manufacturing.

Materials Challenges for Memory

technical paper

The International Conference on Electron, Ion and Photon Beam Technology and Nanofabrication (EIPBN), affectionately known as "3-Beams," is the premier gathering of scientists and engineers who are dedicated to electron, ion and photon lithography, imaging, and analysis; atomically precise fabrication; nanofabrication process technologies and related emerging technologies; and their applications in a broad spectrum of fields. In its 64th meeting, researchers from academia, government laboratories, and industry from around the world meet to present and discuss recent and future trends in these technologies.



[![](https://assets.underline.io/uploads/markdown_image/1/image/4bdf4450aa93073cd684b096b403df2e.png)](https://drive.google.com/file/d/1CPaA3-Yf7_maBxJMUJaUORLF3HGO9CIe/view?usp=sharing) [![](https://assets.underline.io/uploads/markdown_image/1/image/cea8a407085dee5422a2c16738ce27ca.png)](https://eipbn.org/abstracts/2021/)

To register for this event, please follow the link below.

Until now, no in-situ, non-destructive and accurate technology has been invented, which introduces huge difficulties into the superhydrophobic surfaces research and applications. We developed an optical technology to characterize the state of superhydrophobic surface.

Optical Metrology of Characterizing Superhydrophobic States on Patterned Substrates

In direct writing laser lithography, hybrid structures such as gratings on top of resist structures can be generated by combining thermal NIL with DWL lithography. At 120 °C, it is still possible to pattern the resist into at least 4 µm depth without degrading the photosensitive component.

Hybrid structures achieved by direct writing laser lithography - tuning the contrast and surface topography of grayscale photoresist with nanoimprint lithography

Colors produced from nanostructures of different geometries and materials in 2D and 3D made mostly using 3D printing with two-photon polymerization.

Nanostructured Colors from Colorless Materials

We investigated the combination of maskless UV lithography and 2PP (two-photon polymerization) on a standard photo-resist: SU-8. 2PP technology is known to be slow. The advantage of mixing the technologies becomes obvious when some elements of a design can be exposed faster using maskless UV lithography.

Hybrid 2D & 3D Lithography

In this work, we discuss the fabrication process for two types of low-index metalenses composed of air-spaced elements.  First, we discuss the fabrication of our recently demonstrated two element hybrid achromatic metalens (HAML)  that employs nanopillars. Second, we discuss a novel air-spaced, varifocal, metalens that employs nanoholes.

Achromatic and Varifocal Metalens Doublet Fabrication by Two-photon Lithography

We present 3D printed Hybrid metasurfaces that employ variable height (3D) phase plates, pillars, and holes that provide additional degrees of freedom beyond purely planar designs. These structures were 3D printed with two-photon lithography technique.

Hybrid Metasurface Fabrication Using Two-photon Lithography

Molybdenum disulfide, as  a transition metal dichalcogenide, has attracted huge attention for its good optical properties. However, to produce corresponding arrays of nano/microscale devices, resist-based lithography and etching generate permanent contaminations and damages. Here, we report a  method capable of generating arbitrary MoS2 patterns without additional lithography or etching processes.

Multiplexing Rubbing-Induced Site-Selective (RISS) Method for Manufacturing MoS2 Device Arrays

In this work, we study the photo-response properties (e.g., photoresponsivity and noise equivalent power (NEP)) of in-plane MoS2 photodetectors as the function of their geometric dimensions (e.g., thickness, length, and width of photoactive layers) and fabrication conditions (e.g., doping, etching, and substrate choice).

Fabrication optimization of the photo-response characteristics of MoS2 photodetectors for biosensing applications

CVD graphene has brought interest from the biosensors community. Previous work in our group demonstrated a unique fabrication protocol for graphene solution gated field effect transistor (SGFET). This study presents the electrochemical characterization and first biological detection campaign (using aptmamers as probe for hormone detection) of our SGFET sensors.

Electrochemical characterization of graphene gated field effect transistors: route for smart biological sensors

We have developed PHIDL, an open-source GDSII-based CAD tool for Python. PHIDL allows intuitive-but-powerful generation of geometries and has a large library of premade geometry functions ready for use, including basic shapes, text, lithographic test structures, boolean operations, placement and automatic packing algorithms, superconducting nanowires, and photonic routing.
