In this study, we investigated whether UV-cured resin thin films modified by atomic layer deposition (ALD) could be removed completely by dry etching procedures. UV-nanoimprinted deposition masks were removed completely by sequential physical and chemical dry etching procedures, to demonstrate and area selective deposition of aluminum oxide.
