Our goal is to demonstrate a process flow for TSV (nozzle) on one end and another opening (reservoir) on the other end of an SOI. This silicon die will be used as a micro chemical vapor deposition (CVD) chamber, which is a critical component in the nanoscale additive writing process.

EIPBN 2021

Fabrication of Micro Chemical Vapor Deposition Chamber by Dry dry Deep Silicon and Metal-Assisted Etching Techniques

metal assisted etching

chemical vapor deposition

drie

The International Conference on Electron, Ion and Photon Beam Technology and Nanofabrication (EIPBN), affectionately known as "3-Beams," is the premier gathering of scientists and engineers who are dedicated to electron, ion and photon lithography, imaging, and analysis; atomically precise fabrication; nanofabrication process technologies and related emerging technologies; and their applications in a broad spectrum of fields. In its 64th meeting, researchers from academia, government laboratories, and industry from around the world meet to present and discuss recent and future trends in these technologies.
