We developed a versatile room-temperature metal printing technique based on polymer-assisted photochemical deposition (PPD). We demonstrate printing of metal structures with feature sizes as small as 5µm on various substrates, and prove the concept of creating metal-based color filter using PPD.

EIPBN 2021

Additive Manufacturing towards Color Printing via Polymer-Assisted Photochemical Deposition of Metal Thin Films

color printing

printing metal thin film

photochemical reaction

additive manufacturing
