Ferroelectricity boosted gate stacks, such as dual ferroelectric layer and charge trap layer (dual FE-CTL), have been proposed. In this work, interface defect generation and degradation of short time data retention due to cycling on dual FE-CTL devices are investigated by fast I-V measurement. The results reveal significant advantages in  reliability. In addition, lower transient gate current during program is observed, which can explain the root cause of the improvements on dual FE-CTL gate stacks.

IRPS 2024 Main Conference

Investigation of the Impact of Ferroelectricity Boosted Gate Stacks for 3D NAND on Short Time Data Retention and Endurance

3d nand

data retention

endurance

ferroelectricity

reliability

technical paper
