3D packaging (or more generally Heterogenous Integration through advanced packaging innovations) are increasingly necessary to deliver power, performance, area, cost, and time-to-market (PPACT) benefits to remain competitive in the high-performance semiconductor industry [1],[2]. In this talk, the focus is on reliability challenges and opportunities that are amplified because of complex heterogeneously integrated 3D packaging architectures using two examples from AMD’s recent collaboration with U.S. Department of Energy in designing Frontier and El Capitan.

IRPS 2024 Main Conference

2.5D/3D Packaging and Reliability: New Frontiers, Old Paradigms, and Opportunities

packaging

heterogeneous integration

reliability

technical paper
