In this work, we explored the self-heating effect (SHE) and performance analysis of Backside Power Delivery Network (BSPDN) technology for routing logical signals from underlying devices to SRAM macros and 3nm technology nodes. A comprehensive evaluation was conducted on the impact of using BSPDN on the thermal effects and performance of circuits in terms of Power, Performance, Area, and Thermal (PPAT) from devices to circuits.

IRPS 2024 Main Conference

Self-Heating Effect of Device-Circuit with Back-side Power Delivery Network beyond 3nm Node

poster
