A novel vertical channel DRAM cell array transistor has been proposed and verified. A back gate shared by adjacent two word lines has been introduced to have both word line disturb immunity and threshold voltage controllability, while having a small foot print and corresponding scalability. The increased word line coupling has less effect on overall word line disturb immunity, by virtue of insignificant passing gate effects and reduced variability.

IRPS 2024 Main Conference

Effect of Back Gate on Word Line Disturb Immunity of a Vertical Channel DRAM Cell Array Transistor

poster
