Cross temperature effect is a fundamental reliability concern for 3D NAND Flash memory. In this paper we explore the origin of cross temperature reliability by measuring the cell threshold voltage (Vth) distribution at different temperatures. We observe significant cell-to-cell variability in the temperature coefficients causing distribution widening. We provide a conceptual picture to model the distribution widening based on sub-threshold slope factor variation. We also discuss two system level countermeasures to minimize the cross-temperature effects.

IRPS 2024 Main Conference

Cross-Temperature Reliability of 3D NAND: Cell-to-Cell Variability Analysis and Countermeasure
