From over 50 years, dielectric breakdown is a crucial reliability concern in electron devices. Despite various theories accurately replicating breakdown trends in accelerated conditions, discrepancies arise in estimating device lifetime under operating conditions. The latest Carrier Injection (CI) model harmonizes these inconsistencies, revealing dynamic changes in time-to-breakdown E-field dependence. By incorporating trapped charges into CI model, we present a more comprehensive understanding of breakdown, demonstrating that trapped charges enhances reliability by delaying trapping into precursors.

IRPS 2024 Main Conference

The Major Effect of Trapped Charge on Dielectric Breakdown Dynamics and Lifetime Estimation

charge injection

trapped chage

breakdown

**IRPS 2024 Tutorials were held in Dallas, Texas from April 14 to 15, 2024. The IRPS Reliability Year in Review (YIR) session consisted of three presentations reviewing the past year's reliability work by experts in the field for areas of high interest. It was a nice augmentation to the tutorials sessions immediately preceding and attendees were able to obtain keen reliability insights in short amount of time.**
