Wireless interconnected devices have become ubiquitous, with many transformative applications emerging as sensor nodes that scale to smaller dimensions and higher node density. Energy harvesting for sensor systems at the millimeter-scale and microscale has become paramount, where functionality and system lifetime is determined by available power. Energy can be harvested through optical, radio-frequency, mechanical, piezo, thermoelectric and many diverse means [1]. Optical energy harvesting via photovoltaic cells scales efficiently down to the microscale, including sources from outdoor sunlight, indoor lighting, and near-infrared illumination (NIR ~ 850 nm, particularly for biomedical implantable sensors[2]). GaAs/AlAs photovoltaics (PV) provide high power conversion efficiencies for these sources across a broad range of optical spectra Furthermore, GaAs-based PV provides a platform for integrated optoelectronic devices that can be used for low-power optical communications. In this work, we present thin (&lt;8 µm) GaAs PV cells for energy harvesting in microscale systems and heterogeneous integration approaches with low-power CMOS electronics. The PV cell structures consist of a single or dual-junction devices that were grown epitaxially by external foundries. Single junction devices are designed for optical response ranging from outdoor sunlight to 850 nm monochromatic illumination, where lateral series-connected devices may be fabricated to step up voltage output for energy harvesting. Dual junction “segmented” PV devices are designed for monochromatic illumination at 850 nm with target applications for bio-implantable systems. Devices were fabricated using previously established etching, photolithography, and metallization technologies. SiNx passivation layers are used on mesa devices, which also serve as electrical isolation for bonding pads metal interconnects. Fabricated devices are mounted epi-side down on glass substrates for substrate removal using wet chemical etching facilitated by an InGaP etch stop layer. A substrate transfer process is used to flip substrates to a sapphire substrate for device testing or flip chip bonding to silicon CMOS. Single junction and dual-junction PV devices show power density on the order of 1 µW/mm2 under mild 850 nm irradiation with an efficiency &gt;20 %. Experiments using substrate removal utilized a new dual-junction epitaxial growth run where devices exhibited a diode blocking behavior attributed to an improper tunnel junction. Nevertheless, substrate removed devices exhibit power generation and integrity of electrical behavior for both frontside and substrate removed backside illumination. Further progress on substrate removed microscale PV harvesters and flip-chip bonding for device integration will be presented. The authors gratefully acknowledge the National Science Foundation award CBET-2129817 and the National Institute of Health award 1RF1NS128667. J. D. Phillips, Frontiers in Nanotechnology, 3, 633931, 2021 E. Moon et al, … J. D.Phillips, ACS Photonics 8, no. 5 (2021)

EMC 2023

Substrate-Removed GaAs Photovoltaic Cells for Microscale Energy Harvesting

energy harvesting

solar cells

near-infrared

Wireless interconnected devices have become ubiquitous, with many transformative applications emerging as sensor nodes that scale to smaller dimensions and higher node density. Energy harvesting for sensor systems at the millimeter-scale and microscale has become paramount, where functionality and system lifetime is determined by available power. Energy can be harvested through optical, radio-frequency, mechanical, piezo, thermoelectric and many diverse means [1]. Optical energy harvesting via photovoltaic cells scales efficiently down to the microscale, including sources from outdoor sunlight, indoor lighting, and near-infrared illumination (NIR ~ 850 nm, particularly for biomedical implantable sensors[2]). GaAs/AlAs photovoltaics (PV) provide high power conversion efficiencies for these sources across a broad range of optical spectra Furthermore, GaAs-based PV provides a platform for integrated optoelectronic devices that can be used for low-power optical communications. In this work, we present thin (<8 µm) GaAs PV cells for energy harvesting in microscale systems and heterogeneous integration approaches with low-power CMOS electronics. The PV cell structures consist of a single or dual-junction devices that were grown epitaxially by external foundries. Single junction devices are designed for optical response ranging from outdoor sunlight to 850 nm monochromatic illumination, where lateral series-connected devices may be fabricated to step up voltage output for energy harvesting. Dual junction “segmented” PV devices are designed for monochromatic illumination at 850 nm with target applications for bio-implantable systems. Devices were fabricated using previously established etching, photolithography, and metallization technologies. SiNx passivation layers are used on mesa devices, which also serve as electrical isolation for bonding pads metal interconnects. Fabricated devices are mounted epi-side down on glass substrates for substrate removal using wet chemical etching facilitated by an InGaP etch stop layer. A substrate transfer process is used to flip substrates to a sapphire substrate for device testing or flip chip bonding to silicon CMOS. Single junction and dual-junction PV devices show power density on the order of 1 µW/mm2 under mild 850 nm irradiation with an efficiency >20 %. Experiments using substrate removal utilized a new dual-junction epitaxial growth run where devices exhibited a diode blocking behavior attributed to an improper tunnel junction. Nevertheless, substrate removed devices exhibit power generation and integrity of electrical behavior for both frontside and substrate removed backside illumination. Further progress on substrate removed microscale PV harvesters and flip-chip bonding for device integration will be presented. The authors gratefully acknowledge the National Science Foundation award CBET-2129817 and the National Institute of Health award 1RF1NS128667. J. D. Phillips, Frontiers in Nanotechnology, 3, 633931, 2021 E. Moon et al, … J. D.Phillips, ACS Photonics 8, no. 5 (2021)

technical paper
