We report on the growth and characterization of in-situ Al2O3 on (010) β-Ga2O3 deposited using metalorganic chemical vapor deposition (MOCVD) to enhance the dielectric quality and lifetime. The growth of Al2O3 is performed after the growth of β-Ga2O3 without breaking the vacuum in an Agnitron MOVPE reactor with far injection showerhead design using Trimethylaluminum (TMAl) and Oxygen as precursor gas. The interfacial dielectric layer (First 5 nm) is grown at 800 °C to crystallize the interface to have reduced interface trap density and the rest of the dielectric (17 nm) is grown at 600 °C. Thickness of the grown Al2O3 layer was extracted to be ~22 nm using Xray reflectivity measurements. Grazing incident Xray diffraction analysis was performed and polycrystalline inclusions were observed in the grown Al2O3 films. The dielectrics grown at 600 °C exhibited higher interface trap densities (Dt = 3.2×1012 cm-2) and lower breakdown fields (EBR=6 MV/cm) when compared to the dielectrics grown at 800 °C (EBR= 10 MV/cm, Dt=5.4×1011 cm-2) as is evident from the hysteresis and the trap density vs energy characterization which were determined using deep-UV assisted CV measurements and the current-voltage characteristics of the MOS capacitor test structures. The temperature-modulated dielectric sample (interfacial layer grown at 800 °C, and the bulk dielectric grown at 600 °C) has higher breakdown strength (EBR=7.7 MV/cm) and lower trap density (Dt = 1.1×1012 cm-2) compared to the dielectric grown at 600 °C. This is possibly due to the interfacial crystallization of the hybrid dielectric due to the initial growth at higher temperature. Time dependent dielectric breakdown (TDDB) (current vs stress time) was performed to characterize the long-term reliability of the grown dielectrics. From the Weibull distribution plots of the time to breakdown for four different TDDB stress conditions, a shape factor of β &gt; 1 is observed which indicates good statistical uniformity and intrinsic breakdown behavior. The TDDB distribution is much tighter (higher β value) for the 600 °C dielectric, compared to the 800 C grown dielectric. This is possibly due to the short-range ordering of the 800 °C dielectric compared to the 600 °C dielectric, which reduces the long-term reliability of the dielectric. However, for the hybrid dielectric, the time to breakdown is found to be more tightly distributed when compared to both 600 °C &amp; 800 °C dielectric. Based on the E-model (field-based model), the lifetime of the 800 °C can be extended to 10 years if the dielectrics are stressed at 0.7 MV/cm, whereas the lifetime of the hybrid dielectric can be extended to 10 years if it is stressed at 3.1 MV/cm. Thus although the static breakdown voltage and trap densities of the hybrid dielectric are a little inferior compared to the 800 °C dielectric, the long term reliability of the hybrid dielectric is much superior. This approach of in-situ dielectric deposition on β-Ga2O3 can pave the way for promising robust gate dielectrics for future β-Ga2O3 based high performance MOSFETs due to its promise of improved interface and bulk quality and long-term reliability compared to other conventional dielectric deposition techniques. We acknowledge funding from AFOSR MURI program under Award No. FA9550-21-0078 (PM: Dr. Ali Sayir).

EMC 2023

B3/DD02 (Student) Enhancing the Dielectric Performance of Al2O3 on β-Ga2O3 Using Temperature Modulated in situ Dielectric Deposition

tddb

in-situ dielectric

interface traps

mocvd

gallium oxide

We report on the growth and characterization of in-situ Al2O3 on (010) β-Ga2O3 deposited using metalorganic chemical vapor deposition (MOCVD) to enhance the dielectric quality and lifetime. The growth of Al2O3 is performed after the growth of β-Ga2O3 without breaking the vacuum in an Agnitron MOVPE reactor with far injection showerhead design using Trimethylaluminum (TMAl) and Oxygen as precursor gas. The interfacial dielectric layer (First 5 nm) is grown at 800 °C to crystallize the interface to have reduced interface trap density and the rest of the dielectric (17 nm) is grown at 600 °C. Thickness of the grown Al2O3 layer was extracted to be ~22 nm using Xray reflectivity measurements. Grazing incident Xray diffraction analysis was performed and polycrystalline inclusions were observed in the grown Al2O3 films. The dielectrics grown at 600 °C exhibited higher interface trap densities (Dt = 3.2×1012 cm-2) and lower breakdown fields (EBR=6 MV/cm) when compared to the dielectrics grown at 800 °C (EBR= 10 MV/cm, Dt=5.4×1011 cm-2) as is evident from the hysteresis and the trap density vs energy characterization which were determined using deep-UV assisted CV measurements and the current-voltage characteristics of the MOS capacitor test structures. The temperature-modulated dielectric sample (interfacial layer grown at 800 °C, and the bulk dielectric grown at 600 °C) has higher breakdown strength (EBR=7.7 MV/cm) and lower trap density (Dt = 1.1×1012 cm-2) compared to the dielectric grown at 600 °C. This is possibly due to the interfacial crystallization of the hybrid dielectric due to the initial growth at higher temperature. Time dependent dielectric breakdown (TDDB) (current vs stress time) was performed to characterize the long-term reliability of the grown dielectrics. From the Weibull distribution plots of the time to breakdown for four different TDDB stress conditions, a shape factor of β > 1 is observed which indicates good statistical uniformity and intrinsic breakdown behavior. The TDDB distribution is much tighter (higher β value) for the 600 °C dielectric, compared to the 800 C grown dielectric. This is possibly due to the short-range ordering of the 800 °C dielectric compared to the 600 °C dielectric, which reduces the long-term reliability of the dielectric. However, for the hybrid dielectric, the time to breakdown is found to be more tightly distributed when compared to both 600 °C & 800 °C dielectric. Based on the E-model (field-based model), the lifetime of the 800 °C can be extended to 10 years if the dielectrics are stressed at 0.7 MV/cm, whereas the lifetime of the hybrid dielectric can be extended to 10 years if it is stressed at 3.1 MV/cm. Thus although the static breakdown voltage and trap densities of the hybrid dielectric are a little inferior compared to the 800 °C dielectric, the long term reliability of the hybrid dielectric is much superior. This approach of in-situ dielectric deposition on β-Ga2O3 can pave the way for promising robust gate dielectrics for future β-Ga2O3 based high performance MOSFETs due to its promise of improved interface and bulk quality and long-term reliability compared to other conventional dielectric deposition techniques. We acknowledge funding from AFOSR MURI program under Award No. FA9550-21-0078 (PM: Dr. Ali Sayir).
