This paper provides an optimization process of a 100-W three-level flying capacitor totem-pole PFC in USB TypeC Power Delivery (PD) for aircraft applications. The switching frequency and PFC inductor current ripple are varied to set the PFC inductance variation range and design the differential mode (DM) and common mode (CM) filter to meet the EMI requirement in the DO-160 standard. The design process for all the magnetic components is described with results at different switching frequencies and current ripples. The total volume and loss for all cases with both single-stage and two-stage filters are plotted and compared. Pareto fronts for the two cases are drawn to show the optimal design parameters for the application.

IEEE WiPDA 2022

Design of Three-Level Flying Capacitor Totem Pole PFC in USB Type-C Power Delivery for Aircraft Applications

emi filter

flying capacitor three-level converter

power factor correction

technical paper
