GaN power devices have been in mass production for over 12 years [1] and have arguably crossed over the tipping point in adoption with such end-uses as cell phone fast chargers, DC-DC converters for servers, motor drives for electric bicycles and scooters, class-D audio amplifiers, and lidar sensors for autonomous vehicles and robots.  Some of these applications first started using discrete GaN transistors and later converted to GaN integrated circuits.  Others have stayed with discrete devices.  This paper will discuss the reasons for different adoption rates in different applications and will speculate on the changes that will occur due to new GaN transistor performance and new capabilities in integrating functions in GaN.
