United States

In order to evaluate the time evolution of avalanche breakdown in wide and ultra-wide bandgap devices, we have developed a cable pulser experimental setup that can evaluate the time-evolution of the terminating impedance for a semiconductor device with a time resolution of 130 ps. We have utilized this pulser setup to evaluate the time-to-breakdown of vertical Gallium Nitride and Silicon Carbide diodes for possible use as protection elements in the electrical grid against fast transient voltage pulses (such as those induced by an electromagnetic pulse event). We have found that the Gallium Nitride device demonstrated faster dynamics compared to the Silicon Carbide device, achieving 90% conduction within 1.37 ns compared to the SiC device response time of 2.98 ns. While the Gallium Nitride device did not demonstrate significant dependence of breakdown time with applied voltage, the Silicon Carbide device breakdown time was strongly dependent on applied voltage, ranging from a value of 2.97 ns at 1.33 kV to 0.78 ns at 2.6 kV. The fast response time (&lt; 5 ns) of both the Gallium Nitride and Silicon Carbide devices indicate that both materials systems could meet the stringent response time requirements and may be appropriate for implementation as protection elements against electromagnetic pulse transients.

IEEE WiPDA 2022

Reverse Breakdown Time of Wide Bandgap Diodes

wide bandgap

**[DOWNLOAD THE DRC 2021 DIGEST](https://drive.google.com/file/d/17_-pkYf4IBbVuNYgohTf0iZJORVGp_uN/view?usp=sharing)**

**[DOWNLOAD A COPY OF THE FINAL DRC PROGRAM](https://drive.google.com/file/d/1Ek8UIDCowpLq0z2hXav5tn67FboxS03N/view?usp=sharing)**

For almost eight decades, the Device Research Conference (DRC) has brought together leading scientists, researchers and students to share their latest discoveries in device science, technology and modeling. Notably, many of the first public disclosures of key device technologies were made at the DRC. This year marks the 79th anniversary of the DRC—the longest running device research meeting in the world. As we commemorate this meeting, the high-caliber technical sessions will be highlighted by plenary talks and invited talks by international research pioneers and leaders behind modern electronic technology.

Given the ongoing global health concerns associated with COVID-19 (Coronavirus), the DRC leadership has decided to hold the 2021 Device Research Conference in a virtual (online) format. This follows an enormously successful 2020 DRC held virtually, in which we had record attendance and worldwide participation of more than 875 attendees from 33 countries.

The 2021 Conference will feature:

* Informative, timely short courses in rapidly developing fields
* Oral and poster presentations on electronic/photonic device experiments and simulations
* Plenary and invited presentations given by worldwide leaders
* Evening “rump” session
* Strong student participation and Student Paper Awards

DRC is held in coordination with the Electronic Materials Conference (EMC), which will occur the same week, from June 23-25. As has happened in person in past years, in 2021, the virtual DRC and EMC sessions on the shared day, Wednesday, June 23, will be open to all attendees from both conferences. This recognizes the strong interaction between device and electronic materials research and provides fruitful exchanges of information between attendees of both Conferences. For information on the 63rd Electronic Materials Conference, please visit the [EMC 2021 website.](https://www.mrs.org/63rd-emc/)

2021 DRC individual presentation videos will become available in Underline at the end of each technical session. A recording of each full live session with Q&A will be posted later during the conference. To facilitate re-viewing of recorded talks and sessions, the DRC Underline site will remain open through 11:59pm (US EDT) on July 7th. DRC Conference registration will remain open at www.mrs.org/drc-2021/registration through June 30th.

Thank you for joining us at the 2021 Device Research Conference!

**General Chair**
 Zhihong Chen, Purdue University

**Technical Program Chair**
 Becky (R.L.) Peterson, University of Michigan

**Technical Program Vice-Chair**
 Gregg Jessen, BAE Systems

You can register for the 79th Device Research Conference with the following link. https://www.mrs.org/drc-2021

DRC 2021

For almost eight decades, the Device Research Conference (DRC) has brought together leading scientists, researchers and students to share their latest discoveries in device science, technology and modeling. Notably, many of the first public disclosures of key device technologies were made at the DRC. This year marks the 79th anniversary of the DRC—the longest running device research meeting in the world. As we commemorate this meeting, the high-caliber technical sessions will be highlighted by plenary talks and invited talks by international research pioneers and leaders behind modern electronic technology.

In order to evaluate the time evolution of avalanche breakdown in wide and ultra-wide bandgap devices, we have developed a cable pulser experimental setup that can evaluate the time-evolution of the terminating impedance for a semiconductor device with a time resolution of 130 ps. We have utilized this pulser setup to evaluate the time-to-breakdown of vertical Gallium Nitride and Silicon Carbide diodes for possible use as protection elements in the electrical grid against fast transient voltage pulses (such as those induced by an electromagnetic pulse event). We have found that the Gallium Nitride device demonstrated faster dynamics compared to the Silicon Carbide device, achieving 90% conduction within 1.37 ns compared to the SiC device response time of 2.98 ns. While the Gallium Nitride device did not demonstrate significant dependence of breakdown time with applied voltage, the Silicon Carbide device breakdown time was strongly dependent on applied voltage, ranging from a value of 2.97 ns at 1.33 kV to 0.78 ns at 2.6 kV. The fast response time (< 5 ns) of both the Gallium Nitride and Silicon Carbide devices indicate that both materials systems could meet the stringent response time requirements and may be appropriate for implementation as protection elements against electromagnetic pulse transients.

technical paper

Download the proceedings [here](https://underline.io/events/372/lounge)


 The IEEE Workshop on Wide Bandgap Power Devices & Applications (WiPDA) provides a forum for device scientists, circuit designers, & application engineers from the Power Electronics & Electron Devices Societies to share technology updates, research findings, experience & potential applications.

 **Topics of interest**
* Heteroepitaxial & Bulk Materials Growth
* Gate Dielectrics & Surface Passivation
* Device Structures & Fabrication Techniques
* Device Characterization & Modeling
* Very-High Efficiency Or Compact Converters
* Safe Operating Areas Of Wide Bandgap Devices, including Short Circuit, Spike, &Transient Tolerance
* Harsh Environment (High Temperature) Operation & Reliability
* Packaging Power Modules & ICs
* Gate Drive & Other Auxiliary Circuits
* High-Performance Passive Components
* Hard-Switched & Soft-Switched Application Analysis
* Applications in Renewable Energy & Energy Storage, Transportation, Industrial Drives, Grid Power Systems, Space and Aerospace
* Wide Bandgap System Design Philosophies & Strategies
* Radio Frequency (RF) GaN
* Technology Roadmap of Wide Bandgap Including Devices, Applications and Packaging

You must register to attend this event. If you haven't done so already, please use the link below to register for the event. All registered attendees will have access to the event site on November 4th.

Registration Is Required

The IEEE Workshop on Wide Bandgap Power Devices & Applications (WiPDA) provides a forum for device scientists, circuit designers, & application engineers from the Power Electronics & Electron Devices Societies to share technology updates, research findings, experience & potential applications.

We investigate the drift of threshold voltage (VTH) and on-resistance (RON) in p-GaN power HEMTs after being submitted to negative/positive gate stress. Negative (Positive) Gate Stress (NGS/PGS) was applied at a gate-to-source bias of |VNGS| = VPGS = 6 V up to a cumulative stress time of 8×103 s at room temperature. We found that during NGS both VTH and RON increased over stress time, whereas during PGS both parameters decreased and stabilized to the values prior to stress application. This symmetric behavior was maintained after 5 full NGS/PGS stress cycles, indicating the absence of permanent degradation. To further characterize the VTH and RON transients, the NGS/PGS stress cycles were repeated at different temperatures (T=30-105 °C). While VTH exhibited a strong Tdependence (EA ≈ 0.6 eV) during NGS, a negligible variation of the VTH transients with T was found during PGS (EA ≈ 0 eV). Instead, RON transients exhibited approximately the same Tdependence during both NGS and PGS (EA ≈ 0.3-0.4 eV).

Symmetrical VTH/RON Drifts Due to Negative/Positive Gate Stress in p-GaN Power HEMTs

Reliability tests are a decisive step for GaN technology qualification. To evaluate the Mean Time to Failure (MTTF), it is necessary to know well the peak channel temperature (Tpeak) reached at the hottest point of the device. For an AlGaN/GaN High Electron Mobility Transistor (HEMT), this region lies at AlGaN/GaN interface where the two-dimensional electron gas (2DEG) is located near the gate contact. InfraRed (IR) Thermography was performed on our GaN on Si HEMT devices to measure Tpeak. Considering the correction in underestimation of Tpeak temperature, the MTTF was extracted. We also performed Raman measurements and Tpeak was evaluated with the aid of 3-Dimensional thermal simulations. The Tpeak difference between IR and Raman technique is more than 100°C and far from the evaluation of about 40-50°C often found in literature. The reliability measurements show a high robustness and from the Raman approach MTTF is approximately 109 hours instead of the 106 hours estimated with the IR method at Tpeak =200°C.

Peak Channel Temperature Determination for an AlGaN/GaN HEMT with Raman Thermography and MTTF Extraction for Long Term Reliability

This paper reports on the high temperature (HT) robustness of enhancement-mode (E-mode) p-GaN-gated AlGaN/GaN high electron mobility transistors (HEMTs), with an emphasis on the key transistor-level parameters for digital and analog mixed-signal applications. In-situ measurements from room temperature (RT) to 500 °C show that trends in Vth, RON, ID,max and IG,max are largely as expected based on firstorder changes in the semiconductor properties. The fabricated transistors exhibited stable performance over 20 days at 500 °C. To the best of the authors’ knowledge, this work is the first systematic study on the HT performance of E-mode p-GaN-gated AlGaN/GaN HEMTs, and sheds light on their use in mixed-signal and low-voltage power circuits.

High Temperature Robustness of Enhancement-Mode p-GaN-Gated AlGaN/GaN HEMT Technology

In this work, the influence of various oxide electric field (۳ܠܗ (stress conditions on the gate oxide lifetime, gate leakage current, and threshold voltage of 1.2 kV 4H-SiC power planar metal-oxide-semiconductor field-effect transistors (MOSFETs) is investigated. The results suggest that high ۳ܠܗ stress (> 9.4 MV/cm) applied to the gate oxide of commercial SiC power MOSFETs for a certain period degrades the oxide lifetime due to high Fowler-Nordheim (F-N) electron tunneling current followed by hole trapping. Moreover, hole trapping enhances the gate leakage current and reduces the threshold voltage. Therefore, the generation of holes under high electric field conditions should be avoided to ensure the reliability of SiC power MOSFETs.

Effects of Oxide Electric Field Stress on the Gate Oxide Reliability of Commercial SiC Power MOSFETs

瀆 It has been demonstrated that basal plane dislocations (BPDs)-induced stacking faults (SFs) cause body diode degradation in commercial 4H-SiC power MOSFETs, especially with higher voltage ratings. BPDs originate from 4HSiC boule, epi growth, and ion implantation. Considering the lower cost of ion implantation at room temperature (RT), this work investigates the potential of RT ion implantation replacing heated (HT) ion implantation by comparing the influence of both ion implantations on the body diode degradation of commercial 3.3 kV 4H-SiC power MOSFETs. We demonstrate with long-term (up to 1000 hours) forward current stress that RT implantation can keep the body diode degradation of 3.3 kV 4H-SiC power MOSFETs within the specification limits compared with HT implantation.

A Comparison of Ion Implantation at Room Temperature and Heated Ion Implantation on the Body Diode Degradation of Commercial 3.3 kV 4H-SiC Power MOSFETs

This paper presents a comparison of 1.2 kV 4H-SiC MOSFETs and Ti JBSFETs with deep P-well structures. For a fair comparison of the short-circuit characteristics between the MOSFETs and JBSFETs, an innovative design approach for the JBSFETs was implemented to obtain the same specific on-resistance to the MOSFETs. To improve the short-circuit characteristics of the MOSFETs and JBSFETs, channeling implantation was conducted to form a deep P-well structure, that helps reduce the maximum saturation current during the shortcircuit event. Using this approach superior short-circuit characteristics are achieved in the MOSFETs and JBSFETs. However, the JBSFETs provide a shorter shortcircuit withstand time than the MOSFETs due to the high leakage current from Schottky contact. Sentaurus 2D TCAD was used to understand and clarify the short-circuit mechanisms of the MOSFETs and JBSFETs. It was discovered that the MOSFETs failed due to the high current in the channel region, but the failure of JBSFETs happens in the Schottky contact. Moreover, solutions to improve the short-circuit characteristics of the JBSFETs are proposed; a narrow Schottky width and high work function metal.

A Comparison of Short-Circuit Failure Mechanisms of 1.2 kV 4H-SiC MOSFETs and JBSFETs

Neutron-induced failures in power electronics are a source of concern in many high-reliability applications. This paper describes how to estimate the device's decreased lifetime expectancy based on its usage. The physical mechanism, Failure in Time (FIT) statistics and FIT rate calculation methodology are presented. Several Microchip SiC MOSFETs and Schottky barrier diodes at different voltage ratings were tested, and the results for the excess FIT rate calculation based on various factors such as operation voltage, altitude, device area, latitude, and duty factor are presented.

Failure Rate Calculation Due to Neutron Flux with SiC MOSFETs and Schottky Diodes

The same core device model is shown to accurately reproduce the current-voltage and capacitance-voltage characteristics of enhancement-mode GaN 100 V power transistors of various sizes. Using linear scaling, excellent agreement with measurements is achieved over an order of magnitude variation in total gate width. Fractional variation in onresistance is shown to decrease with increasing transistor size, with implications for integrated circuit-sized transistors where gate width decreases by up to 5 orders of magnitude.

Scaling of EPC’s 100 V Enhancement-Mode Power Transistors

In this paper, we discuss how advancements in the integration of gallium nitride (GaN) power ICs leads to faster switching, higher efficiencies, simplifier designs and improved reliability. Navitas’ integrated GaNSense™ technology features provide real-time sensing and protection to achieve these new levels.

Advancement in Integration for GaN Power ICs

In this study, the impact and correlation of drainand gate-voltage stress on the threshold voltage of commercially available p-gate GaN HEMTs are investigated. This is based on single-pulse measurements acquired with a custom pulse setup, thus the transient behavior can be determined and subsequently translated into dc characteristics. As a novelty, measurements of the threshold voltage for short-circuit stress of up to 600 V are shown. As a result, a constant threshold voltage shift is observed for on-state drain-voltage stress, while off-state drain-voltage and gate-voltage stress lead to a threshold voltage instability. Finally, drain stress and gate stress appears to superimpose, consequently already application-relevant gate-driving conditions show a drastic impact of the short-circuit capability.
