Novel Sensing Technique for Non Destructive Composites Monitoring

The real time non-destructive monitoring of stresses and temperature is one of the most demanded solutions in the field of sensor technologies. One of the most prospective technologies addressing this problem is a novel sensing technique for non-destructive monitoring utilizing ferromagnetic wire inclusions presenting the high frequency magnetoimpedance, MI, effect quite sensitive to tensile stress and magnetic field [1]. One of the advantages of this technology is that proposed free space microwave spectroscopy allows remote monitoring of external stimuli, like stress, magnetic field or temperature. The glass-coated microwires with typical diameters from 1 to 50 Î¼m can provide new functionalities such as improved mechanical and corrosive properties, adherence with polymeric matrices and biocompatibility [2]. In the present paper a novel sensing technique for direct non-destructive and non-contact monitoring of the composite polymerization utilizing ferromagnetic glass-coated microwire inclusions with magnetic properties sensitive to tensile stress and temperature is described. We provide in-situ studies of the evolution of the hysteresis loop of arrays consisting of Co- rich (Fe3.8Co65.4Ni1B13.8Si13Mo1.35C1.65) microwires during the composites matrix polymerization. We observed remarkable change of the hysteresis loops upon matrix polymerization: remarkable coercivity change and transformation of linear hysteresis loop into rectangular in the arrays with Co-rich microwires placed inside the matrix (see Fig.1a). Using the free space technique we observed considerable variation of the Transmission parameter of the microwires array in the range of 4-7 GHz upon the matrix polymerization (see Fig.1b). Observed dependencies are discussed considering heating during the matrix polymerization measured using a standard thermocouple (Fig.1c) and the matrix shrinkage and their influence on magnetic properties and MI effect of glass-coated microwires.
