In this research, we investigated the effect of low sputtering power for 5 nm thick ferroelectric nondoped HfO2 gate insulator formation to improve the operation speed and operation voltage of scaled MFSFET. Sputtering power of 50 W for 5 nm thick ferroelectric nondoped HfO2 gate insulator formation was effective not only to increase the memory window but also to reduce the low frequency noise spectral density of MFSFET with the improvement of interface property.

DRC 2022

Ultrathin Ferroelectric Nondoped HfO2 for MFSFET with High-speed and Low-voltage Operation

rf magnetron sputtering

5 nm thick ferroelectric nondoped hfo2

mfsfet
