The space domain is becoming ever more congested and complex. The number of satellite launches is growing exponentially; commercialisation of various space-based imaging services and the number of space-capable nations continues to rise; and adversaries increasingly operate in grey-zones, attempting to evade attribution of their activities. Simultaneously, the variety and quantity of available data is growing, providing a complex challenge for space analysists trying to build an accurate picture. Machine Learning (ML) techniques can offer assistance to analysts in managing these burdens: ML can exploit excess data to provide timesaving, wider-reaching, or novel capability, and release human effort to focus on complex or higher-priority issues.

This presentation demonstrates the feasibility and effectiveness of machine learning models for satellite characterisation. Dstl has developed models to predict the operational status and the bus (structural frame type) of satellites using ground-based time-series observations of reflected sun-light or reflected radar. We found classical ML models (e.g. Random Forests) performed as well as Deep Learning approaches: our LSTM (long short-term memory) models struggled to retain their high performance when generalising to non-iid (independent identically distributed), out-of-distribution samples. The full range of characterisation tasks is significantly broader than those investigated here and considerable scope remains for further low-TRL research.

Data was a critical and limiting factor throughout this work. Based on the sources available, Wide Field Lens Array telescopes offered the best data for LEO characterisation while traditional commercial world-wide networks of Newtonian telescopes offered the best data for GEO characterisation. Open-source labels were not always available to high enough accuracy, limiting model performance in some cases. Furthermore, open-source labels are not openly archived, complicating the use of historic observations.

NAML 2022

Machine Learning for Satellite Characterisation
