Galileo is currently testing its Open Service Navigation Message Authentication (OSNMA). OSNMA is based on authenticating the navigation data with cryptographic features, assuring the origin of the data. However, OSNMA does not explicitly authenticate the GNSS signals, and signal authentication is necessary to protect the signal time of arrival. Otherwise, an adversary can replay the signals and alter the time of arrival, spoofing the position even if the data used to calculate it is authentic.

This work describes a method for protection against signal replay attacks based on Galileo OSNMA and analyses its feasibility in smartphones.

The OSNMA protocol is based on the transmission of message authentication codes and the later disclosure of a cryptographic key used to generate them. Once the key is authenticated, the receiver authenticates the navigation data with the codes and the key, obtaining a data-authenticated position.

As in most cryptographic systems, the authentication codes are unpredictable. This feature makes the Galileo signal unpredictable as well. Our method is based on leveraging this signal unpredictability in combination with assistance information, to protect against signal replays.

The method has been tested in smartphones (Samsung S10 and Xiaomi Mi8) using Android, which provides the GNSS raw measurements and bitstreams. While the Galileo E1-B bitstreams are provided only intermittently, the complete authentication process is performed in less than ten seconds for the first satellite and the total time for authenticating four or more satellites is less than two minutes.

The results show that, while signal antireplay is not the primary purpose of OSNMA, bit unpredictability combined with accurate time synchronization can be exploited to make spoofing more difficult.

Navigation 2021

Using Navigation Message Authentication in Smartphones to Protect against Replay Attacks
