A combined experimental/simulation analysis has been performed to study the gate reliability of GaN-HEMTs with p-type gate under pulse stress conditions. Results show that the time-dependent gate breakdown (TDGB) can be determined by two factors: i) the total ON-time during which the device is subjected to a positive gate bias before the failure; ii) the number of pulses, hence the number of switching phases from OFF- to ON-State and vice versa. The severity of the degradation ascribed to transition phases depends on the OFF-time (tOFF) and transition time (tTR = tRISE = tFALL). In particular, the shorter tOFFand tTR, the higher the Schottky junction voltage drop and the current peak during the switching phase, respectively. The higher voltage drop is ascribed to the semi-floating potential of the p-GaN layer.

IRPS 2022 Main Conference

Gate Reliability of p-GaN Power HEMTs Under Pulsed Stress Condition

tcad modeling.

pulsed gate stress

p-gan gate

hemts reliability

gallium nitride
