Integrating CMOS circuits and qubits at cryogenic temperatures a key challenge to enable up-scaling of quantum computers. One approach to reduce power consumption is to optimize designs towards operation at lower supply voltages. However, this reduces the tolerable margins on variability and device to device variations. In this study, we present the time-zero variability and mismatch of nMOS transistors from room temperature down to 4K. We investigate the physical origins of variability at cryogenic temperatures. We estimate the influence of different on-current variability sources and observe that another source of mismatch, likely contact resistance, becomes dominant at low temperatures.

IRPS 2022

Temperature Dependent Mismatch and Variability in a Cryo-CMOS Array with 30k Transistors

cryogenic cmos

variability

quantum computing

technical paper
