This work shows an approach to carry out the de-layering, through a series of smart solutions, of the die surface of AlGaN/GaN HEMT with 3 metal levels plus Cu-RDL, after to have performed Fault Localization in the best way – from resolution and wavelengths detection point of view – from the backside of the device without Silicon substrate, that means the final die thickness is ≈ 7µm.
This approach allows advanced physical analysis on AlGaN surface, observing at high resolution and magnification defective points and comparing them with other close areas, improving consistently the global information about the die surface.

IRPS 2022

Failure Analysis of AlGaN/GaN Power HEMTs through an innovative sample preparation approach
