The electrical reliability of 1 μm pitch wafer-to-wafer(W2W) Cu/SiCN hybrid bonding interface is evaluated.Breakdown voltage distributions of the W2W hybrid stack wereacquired using the controlled-IV method. Assuming a power lawmodel, extrapolation towards use conditions confirm a lifetimeabove 10 years, with a power law exponent above 10 fortemperatures under 175 C. The conduction mechanism along theCu/SiCN hybrid bonding interface is found to be Poole-Frenkelemission with energy barrier equals 0.95 eV. Mobile copper couldonly be observed at temperatures above 200 C and for fieldsabove 1.5 MV/cm, confirming the good robustness against copperdrift for this bonding interface.

IRPS 2022

Reliability Investigation of W2W Hybrid Bonding Interface: Breakdown Voltage and Leakage Mechanism

controlled-iv

w2w hybrid bonding

reliability

technical paper
