Several cyber-physical systems use real-time restart-based embedded systems with the Simplex architecture to provide safety guarantees against system faults. Some approaches have been developed to protect such systems from security violations too, but none of these approaches can prevent an adversary from modifying the operating system or application code to execute an attack that persists even after a reboot. In this work, we present a secure boot mechanism to restore real-time restart-based embedded systems into a secure computing environment after every restart. We analyze the delay introduced by the proposed security feature and present preliminary results to demonstrate the viability of our approach using an open-source bootloader and real-time operating system.

IEEE RTSS 2021

Enabling Secure Boot for Real-Time Restart-Based Cyber-Physical Systems

rtems

u-boot

secure boot

delays

codes

computer architecture

embedded systems

safety

cyber-physical systems

real-time systems
