Achieving a strong perpendicular magnetic anisotropy is of great importance for materials intended for use in spintronics devices. Perpendicular anisotropy in magnetic multilayers arises from the broken symmetry at the interfaces due to the enhanced orbital and spin moments relative to the bulk system1. In order to accurately describe the quasi-static properties of these materials using a macrospin approach, the inclusion of both second-order (K2) fourth-order (K4) uniaxial anisotropies is essential. Beik Mohammadi et al2 have shown that lateral inhomogeneities of the second-order uniaxial anisotropy in thin films with perpendicular uniaxial anisotropy can give rise to higher-order anisotropy contributions. Here, we report on the study of the layer to layer variation of the second-order perpendicular anisotropy in magnetic bilayers and its influence on the quasi-static properties. We analyze the results of micromagnetic simulations3 in magnetic bilayers using a macrospin model. We show that in order to describe the micromagnetic simulation data using macrospin model, one requires a fourth-order uniaxial anisotropy contribution although the underlaying micromagnetic model does not include such term. Quasi-static calculations show that the fourth-order uniaxial anisotropy is caused by the deviation of the magnetization from the applied field direction.References: 1. J. M. Shaw, H. T. Nembach and T. J. Silva, Physical Review B 87 (5), 054416 (2013). 2. J. Mohammadi, K. Cole, T. Mewes and C. Mewes, Physical Review B 97 (1), 014434 (2018). 3. T. Mewes, C. Mewes, MATLAB based micromagnetics code M3, (2018). URL http://magneticslab.ua.edu/micromagnetics-code.html

MMM 2020

Micromagnetic Simulations of the Quasi-static Properties of Dissimilar Bilayers

The 65th Annual Conference on Magnetism and Magnetic Materials (MMM 2020) was held in a virtual form. The COVID-19 pandemic, with its associated uncertainty about international travel and the ability to gather in large groups, meant that the Steering Committee decided to cancel the face-to-face meeting that had been planned in Palm Beach, Florida November 2-6, 2020.

We were reluctant to give up the benefits of meeting face-to-face, and know that shifting to a virtual conference is a significant change for this community. Nevertheless, we are first and foremost concerned about the health and safety of all our Conference participants and their loved ones on returning home after travelling.

The MMM 2020 Steering Committee was working exceptionally hard, along with our sponsors, the IEEE Magnetics Society and AIP Publishing, to make this event serve the needs of our participants, who live in time zones all around the globe, in the best possible way.

You need a ticket to explore this event.

If you have already registered for MMM 2020, and you have already created an account, then you
just need to login (above).

If you have already registered for MMM 2020, but you have not yet created an account, then you
need to click on &quot;create an account&quot; (above) and then login.

Forgot your password? Go to
https://www.underline.io/log-in

If you have not yet registered for MMM 2020 but would like to do so, go to
https://magnetism.org/register

Still need help? Contact our team!


poster

Pure spin currents have been ubiquitous in contemporary spintronics research. Despite its pro- found physical and technological significance, the detection of pure spin current has largely remained indirect, which is usually achieved by probing spin-transfer torque effects or spin-to-charge conversions. By using scanning transmission X-ray microscopy, we report the direct detection and spatial mapping of spin accumulation in a nonmagnetic Cu layer without any direct charge current injection. Such a pure spin current is induced by spin pumping from a NiFe layer and is not accompanied by concomitant charge motion. The observed frequency dependence indicates that the signal is dominated by a coherent, pure spin current, but the magnitude of the spin accumulation suggests also possible additional thermal contributions. Our technique takes advantage of the X-ray magnetic circular dichroism and the synchronization of microwave with X-ray pulses, which together provide a high sensitivity for probing transient magnetic moment. From the detected X-ray signals, we observe two distinct resonance modes induced by spin pumping, which, based on micromagnetic simulations, we attribute to non-linear microwave excitations. Our result provides a new pathway for detecting pure spin currents that originate from many spintronics phenomena, such as spin Hall and spin Seebeck effects, and which can be applied to both metal and insulator spin current sources [1]. Work at Argonne, including experimental design and measurement, sample fabrication, data analysis, and manuscript preparation, was supported by the U.S. Department of Energy (DOE), Office of Science, Basic Energy Sciences, Materials Science and Engineering Division under Contract No. DE-AC02-06CH11357. Use of the Stanford Synchrotron Radiation Light source, SLAC National Accelerator Laboratory, is supported by the U.S. Department of Energy, Office of Science, Office of Basic Energy Sciences under Contract No. DE-AC02-76SF00515. W.Z. acknowledges the DOE visiting Faculty Program.References: 1.) “Direct Observation of spin accumulation in Cu induced by spin pumping” J. Ding, W. Zhang, B. Jungfleisch, J.E. Pearson, H. Ohldag, V. Novosad, A. Hoffmann, Phys. Rev. Res vol 2(1), p. 013262 (2020)

Direct Observation of Spin Accumulation in Cu Induced by Spin Pumping

This paper presents engineering of magnetic domains and perpendicular magnetic anisotropy (PMA) in magnetic thin films and multilayer (ML) employing ion-beam irradiation [1]. Two model systems have been selected for this study namely, amorphous Tb-Fe-Co (200 nm) film and ultrathin Co/Pd ML (Si (substrate) / Ta (30) / Pd (30) / [Co (3) / Pd (8)] ×50 / Pd (12) Å) which show strong PMA in the pristine state, however, the origin of PMA is different for both the systems. The pristine Tb-Fe-Co film depicts a rectangular hysteresis loop and elongated, inter-connected maze-like magnetic domains with strong out-of-plane contrast. Irradiation at higher fluences (≥1015 ions/cm2) of Ar+ ions at an energy of 200 keV results in transformation of magnetization reversal mechanism from rapid domain wall motion to nucleation and propagation of reverse domains due to the pinning of domain walls. The elongated magnetic domains get fragmented with reduced contrast and interestingly inhomogeneous flux closure patterns are observed at higher fluences, indicating a spin reorientation transition, as shown in Fig. 1 (a). The modifications in magnetic properties are correlated with the structural investigations which reveal the crystallization of Fe-Co phase in the amorphous Tb-Fe-Co matrix at higher energy and fluences of the projectile ions. On the contrary, ion-induced intermixing at the interfaces for perpendicularly magnetized ultrathin Co/Pd ML causes amorphization for the pristine poly-crystalline films. In this case, low energy ion-irradiation (50 keV) does not have significant role in modifying the microstructure, however, control of pinning sites can be achieved through variable fluences which play an important role in the modification of magnetic domains, as depicted in Fig. 1 (b). Micromagnetic simulations on domain modification complement the experimental results.References: 1. J. Fassbender, D. Ravelosona and Y. Samson, Journal of Physics D: Applied Physics 2004, 37 (16), R179-R196.

Engineering Magnetic Domains in Perpendicularly Magnetized Thin Films and Multilayers Using Ion-beam Irradiation

The Dzyaloshinskii-Moriya interaction (DMI) plays a crucial role in the stabilization of chiral spin textures [1]. Interfacial DMI (iDMI) induced by a lack of inversion symmetry and strong spin orbit coupling at the interface of Ferromagnet/Heavy Metal (FM/HM) heterostructures provides various opportunities for future spintronic devices. Recently, iDMI in a thin film of NiFe/Graphene (NiFe/Gr) heterostructures has been detected using Brillouin light scattering [2] and using spin-polarized electron microscopy [3]. In this study, we propose a simple method of measuring DMI by using the Bragg magneto-optical Kerr effect (MOKE). We observe an asymmetric shift in the hysteresis loop, which is proportional to the strength of iDMI [4]. Here, we utilize Bragg-MOKE in longitudinal mode to which occurs when a broad polarized beam is incident on a periodic array of the magnetic features with size comparable to the wavelength of laser. We have investigated the hysteresis loop shift for 1st and 2nd order of diffraction in off-specular geometry for both patterned graphene (Gr/NiFe(10nm)/Ta) and reference (NiFe(10nm)/Ta). We used triangular pattern (Fig. 1) as proposed in Ref [4]. We found a shift in hysteresis loop for the Gr/NiFe/Ta sample (Fig. 2), which likely due to the presence of iDMI that was previously measured using BLS [2]. Hence, the Bragg-MOKE technique can be a potential technique for rapid quantification of iDMI in magnetic heterostructures. We will also present variable field magnetic force microscopy (MFM) and micromagnetic simulations to support these results.References: 1. M. Bode, et al., Nature 447, 190 (2007). 2. A. Kumar, et al. Phys. Rev. B 99.3,035402 (2019). 3. H. Yang, et al. Nat. Mater. 17, 605 (2018). 4. D-S Han, et al. Nano Lett. 16, 4438 (2016).

Evidence of the interfacial Dzyaloshinskii-Moriya interaction in Ni80Fe20/graphene using Bragg-MOKE

The perpendicular magnetic media has the potential to improve data storage beyond 1 Tb/in2. Improving data density is a major challenge in data recording industries due to its sustainability and performance issues [1]. In the present study, by employing Ti as under-layer (UL) and spacer-layer (SL) the bulk perpendicular magnetic anisotropy (PMA) of Tb-Fe thin films is found to be improved considerably. 100 nm thick Tb-Fe film devoid of UL exhibited a maze-like domain pattern with strong out-of-plane (OOP) contrast. With 10 nm thin Ti UL, the domain width, and the OOP contrast of Tb-Fe (100 nm) film were found to improve considerably (fig. 1). Accordingly, the coercive field for Tb-Fe film with Ti UL was doubled when compared with the bare Tb-Fe film. The possible reason for the enhancement in OOP properties could be due to the lateral extent of d-d hybridization that exists at the interface. Similarly, PMA and domain areal density also increased by placing a 2 nm thin Ti SL: Tb-Fe (100 nm) / Ti (2 nm) / Tb-Fe (100 nm) (fig. 1). Here, we observed a large dipolar coupling that exists between the top and bottom Tb-Fe layers. The Hc of about 0.5 T observed for bare Tb-Fe (200 nm), was found to increase to about 1 T for the Tb-Fe films with Ti SL. Interestingly, Tb-Fe film with SL exhibited a hybrid domain pattern probably due to the bottom Tb-Fe layer. Thus, Ti when used either as UL or SL improved the OOP magnetic properties of Tb-Fe thin films considerably. The fundamental observation and understanding will have a significant impact on perpendicular media which may also useful in other areas of spintronic applications.References: 1. K. Tang, et. al, IEEE transactions on magnetics, Vol. 45 p. 786-792 (2009).

Effect of Ti as an Under and Spacer-layer on the Perpendicular Magnetic Anisotropy of Tb-Fe Thin Film

Atomistic spin models [1] provide a natural bridge between electronic and micromagnetic length scales, where the magnetic properties are described by localised atomic spins within the Heisenberg model. The model parameters can be calculated ab-initio but the macroscopic magnetization dynamics and properties can also be simulated. While powerful, atomistic models are computationally expensive. A particular difficulty is the calculation of long-range dipole-dipole interactions, arising from the stray magnetic fields of localised atomic moments and causes complex magnetisation structures, such as magnetic vortices or Skyrmions. The dipole -dipole interactions are typically solved using a Fast-Fourier-Transform (FFT) [2] or the Fast Multipole Method (FMM) [3]. However, for atomistic simulations the continuum approximation does not accurately reflect the local dipole-dipole interactions at the atomic level and leads to systematic errors in the calculation of the dipole field. A brute force atomistic dipole-dipole approach is infeasible for the time (nanosecond+) and length (100 nm+) scales needed to extract useful data. Here we present modifications to the VAMPIRE software package [1] to include accurate and scalable calculations of dipole-dipole interactions for improved performance and scalability on ARCHER, the UK national supercomputer. We have developed a space-time hierarchical calculation of the dipole field calculation with order NlogN scalability with problem size, a comparison to the brute force tensor approach [4] is shown in Fig. 1. Our novel approach combines exact near-field computation of the dipole field with an M-Level hierarchical representation of the far-field dipole field [5]. The method is hierarchical in time and space, since the far-field time-evolution of the magnetization is much slower than the near-field which changes on the femtosecond timescale. Our improved algorithm enables the inclusion of accurate dipole-dipole interactions in atomistic simulations for large system sizes in the micrometre range for the first time.References: [1] R. F. L. Evans et al, J. Phys.: Condens. Matter 26, 103202 (2014) [2] S. Yuan and H. Bertram, IEEE Trans. Mag. 28, 2031 (1992) [3] G. Brown et al, IEEE Trans. Mag. 40 2146 (2004) [4] G.J. Bowden et al., J. Phys. Condens. Matter 28, 066001 (2016) [5] J.J. Miles and B.K. Middleton, J. Magn. Magn. Mater. 95, 99 (1991)

Scalable space and time hierarchical dipole-dipole interactions in the VAMPIRE code

With the development of electronic low-dimension systems, numerical modeling has become a powerful method for studying and predicting the physical properties of materials. To model dynamic magnetic systems the micromagnetic approach [1] and the methods of GPU acceleration of calculations on the video core of the system [2] are successfully applied. In our work, this approach is used to simulate the effect of nonlinear autoresonant excitation [3, 4] of nanoscale films of yttrium iron garnet (YIG) by a weak external magnetic field. The proposed analytical equations for autoresonance do not take into account a number of important real conditions, for example: attenuation, three-dimensional geometry of the sample, dipole – dipole interaction of spins, surface anisotropy, etc., which does not allow one to directly verify the theoretical model in practice. The aim of the work was to find the conditions for the excitation of autoresonance in a film with some real physical parameters using micromagnetic simulation in the MUMAX3 software. As a planar model, a YIG film with a size of 1600 × 1600 × 160 nm was chosen. The film thickness was taken to satisfy the conditions of a single-mode spin wave excitation and proximity to real planar samples. During simulations the sample was separated into rectangular elements in the form of cells, the interactions between them were calculated by using the Landau-Lifshitz equation. Since the YIG has the minimum level of attenuation of the magnetic subsystem, the damping parameter was excluded at this stage. Then the sample saturated along the axis of easy magnetization by H = 20 kOe was excited by a weak perpendicular pump field h with an amplitude of about 1 Oe. As a result, the stable nonlinear regime of excitation of magnetic oscillations of high magnitude in the film by a chirp rate of the pump field frequency was obtained in in the MUMAX3 simulations for the first time - the autoresonance effect. For the modelled YIG film the optimal chirp rate was a 4.3×10^16 s^(– 2). Finally, the full conditions for the autoresonance excitation of magnetization in the quasi-three-dimensional magnetic film by numerical methods were defined. Supported by the RFBR grant No. 19-32-90014.References: 1 A. Vansteenkiste, J. Leliaert, M. Dvornik, M. Helsen, F. Garcia-Sanchez // AIP Advances. 2014. Vol. 4. P. 107133. 2 V. S. Teplov, V. D. Bessonov. Resource and Mechanics of materials and structures. 2018. V. 6.P. 222—228. 3. S.V. Batalov, A. G. Shagalov. Physics of Metals and Metallography, 2010. Vol 109, N1, P. 3-8 . 4 S,V. Batalov, A. G. Shagalov.. Physics of Metals and Metallography, 2013, Vol 114, N 2, P. 115–119

Micromagnetic modeling magnetization excitation by a resonance

Spherical nanoparticles with hollow structure have received much attention because of their unique magnetic features reflecting their large surface area [1,2]. Recent works suggested the formation of a spin vortex for hollow spherical submicron Fe3O4 particles, whose stability is enhanced with increasing the diameter [3]. In this work, the formation mechanism of spin vortexes have been studied for a hollow submicron sphere using micromagnetic simulations, where possible realization of a double vortex reflecting the hollow structure was revealed. The magnetization reversal and magnetic configurations under magnetic fields along the [100] or [111] axis were studied using OOMMF for a single hollow Fe3O4 spherical particle with the varying diameter (d = 300 - 700 nm) and inner/outer diameter ratio (γ = 0 - 0.75). Electron holography was also performed for 400- nm hollow spheres to directly characterize a magnetic state. Figure 1 shows a typical example of the M-H curves for a hollow sphere (d = 300 nm, γ = 0.5). Before entering a single vortex state (phase IV) typically observed in a solid sphere, two types of vortex structures are formed for a hollow sphere, associated with multi-step magnetization changes. We find that as the magnetic field is reduced from high fields, a clockwise and anti-clockwise vortices are formed at the ends of the sphere (phase II) and then transform into a single vortex with cores displaced by changing a magnetic field (phase III). The formation of such double vortices can be due to reduced Zeeman energy by spins at and around the equatorial plane of the sphere. With increasing d or γ, a field range, where the phases II and III are stabilized, expands for both [100] and [111] field orientations. Magnetic phase images obtained by electron holography revealed no significant stray field around the hollow sphere in zero fields, being consistent with the formation of a spin vortex.References: 1] H. Khurashid et al., Scientific Reports 5, 15054 (2015) 2] Y. Liang et al., Colloids and Surfaces A 530 191-199 (2017) 3] M. Chiba et al., Journal of Magnetism and Magnetic Materials 512 167012 (2020)

Possible realization of double spin vortex state in hollow submicron particles

The ground state of nanoscale circular magnetic disks of certain geometric aspect ratios is a spontaneously forming stable vortex configuration with circulating in-plane magnetization and a vortex core pointing out-of-plane. Resonantly exciting the vortex core via either an rf magnetic field or an rf spin-polarized current yields a gyrotropic motion around its equilibrium position, characterised by a specific eigen-frequency, which depends on the material parameters and the disk geometry [1]. Such oscillations, which can be read out via periodic magnetoresistance changes, generate rf signals with high quality factors (>10000) in the sub-GHz bandwidth [2,3]. While all these features make vortex-based nano-oscillators interesting as nanoscale rf sources, the major drawback remains their low frequency tunability associated with the linear characteristics of the gyrotropic mode. Here, we investigate, by micromagnetic simulations, the role of magnetostriction in improving the tunability of vortex nano-oscillators. Specifically, we consider a double-disk structure comprising magnetostrictive (CoFe) and non-magnetostrictive (Py) layers separated vertically by a non-magnetic (NM) spacer. We show that, when the two vortices have different eigen-frequencies and the magnetostatic coupling between them is sufficiently strong, the stress-induced magnetoelastic anisotropy can lead to the synchronized gyration of the two vortex cores (Fig. 1). The stress-induced transition from double-frequency to single-frequency dynamics is mostly controlled by the polarization of the vortices and the magnetostatic coupling strength (i.e. spacer thickness). These findings offer a frequency tunability of vortex-based oscillators via mechanical stress, which can be generated and controlled electrically, for example, using piezoelectric substrates [4]. Funding from the EU Horizon 2020 project No. 737038 (TRANSPIRE) is acknowledged.References: [1] K. Yu. Guslienko, et al, J. Appl. Phys. 91, 8037 (2002). [2] A. Dussaux, et al, Nat. Commun. 1, 1 (2010). [3] N. Locatelli, et al, Appl. Phys. Lett. 98, 062501 (2011). [4] M. Filianina, et al, Appl. Phys. Lett. 115, 062404 (2019).

Stress-Induced Modification of Gyration Eigen-Frequencies in Stacked Double-Vortex Structures

Recent improvements in nanoparticle synthesis have allowed the application of magnetic nanoparticles (MNPs) in many fields where particle size control is key, such as data storage, spintronics or biomedicine, in which drug delivery and cancer treatment using hyperthermia stand out. In MNP systems, shape can trigger magnetostatic anisotropy effects induced by the demagnetizing factor. This feature is most notorious in highly degenerated systems on which shape anisotropy can be induced to alter properties like coercive field and remanence of non-interacting MNPs. In addition, magnetostatic dipolar interactions between MNPs can be tuned in disordered and crystalline structures by adding non-magnetic coatings, which can also control the lattice parameter, in a core-shell scheme, thus affecting the effective anisotropy of the system. This work focuses on the angular study of magnetization reversal processes in quasi-spherical (ε~1) single MNPs with different shapes and magnetic properties. Simulations show different hysteresis loops for different sphericalnesses of the MNPs, which can be related to the presence of different magnetization pinning events at the sharp edges of less spherical MNPs[Fig. 1]. Moreover, the effect of dipolar interactions has been tested out with simulations of the remanent state in MNP superlattices with simple, body-centered and face-centered cubic arrangements[Fig. 2].References: D.L. Huber, small., Vol. 1(5), p.482-501 (2005) D. Kim et al., Journal of Magnetism and Magnetic Materials., Vol. 320(19), p.2390-2396 (2008) Q. Li et al., Scientific Reports., Vol. 7, p.9894 (2017) D. Peddis et al., Chemistry of Materials., Vol. 25(10), p.2005-2013 (2013) A. Vansteenkiste et al., AIP Advances, Vol. 4, p.107133 (2014)

Shape-related Effects on Ferromagnetic Nanoparticles: A Micromagnetic Approach for Highly Diluted and Highly Ordered Systems

Inhomogeneous magnetic phases like magnetic vortex are expected to open up a wide range of opportunities both from a fundamental and technological perspective. Asymmetric nanostructures offer alternative data storage possibilities by suggesting a control over the vortex formation and thereby chirality [1-3]. Asymmetry introduced in the geometry also has a strong impact on magnetization reversal. Increased coercivity, remanence, and switching field distribution with the degree of asymmetry establishes the existence of an induced anisotropy, which in turn could even destabilize the magnetic vortex depending on the degree of asymmetry in a particular geometry [4]. Following these ideas, in this work, we investigate how the asymmetry modifies the magnetization reversal in hemispherical shells. We address this issue by breaking the symmetry of non-interacting hemispherical cap structures through a thickness modulation inclined at an angle with the symmetry plane and by analyzing the magnetization reversal mechanism for varying thicknesses. Micromagnetic simulations indicate that the asymmetric nanocaps reverse through the propagation of a curling state, while in the symmetric caps, magnetization reversal happens via coherent rotation. With an increase in thickness, the field at which curling state nucleates, shifts towards a higher applied field. The non-uniform magnetization reversal is apparently due to the altered energy contributions resulting from the asymmetry introduced in the nanocaps.References: [1] M. Schneider, H. Hoffmann, and J. Zweck, Appl. Phys. Lett., Vol. 79, p.3113 (2001) [2] D. B. Gopman, Y. P. Kabanov, J. Cui, et al., Appl. Phys. Lett., Vol. 109, p.082407 (2016) [3] J. Rothman, M. Kläui, L. Lopez-Diaz, et al., Phys. Rev. Lett., Vol. 86, p.1098 (2001) [4] K. M. Wu, J. F. Wang, Y. H. Wu, et al., J. Appl. Phys., Vol. 103, p.07F314 (2008)
