Bit-patterned media recording (BPMR) is a promising candidate for the next generation of magnetic storage system to achieve areal density beyond one terabit per square inch [1]. For increasing a density of BPMR, the bit islands must be close to each other. However, we have faced the problem of intersymbol interference (ISI) and intertrack interference (ITI) that severely degrade the performance of BPMR system [2]. In this paper, we propose iterative detection with multilayer perceptron (MLP) for BPMR to improve bit error rate (BER) performance. Fig. 1 shows the block diagram of proposed iterative detection scheme that consists of partial response maximum likelihood (PRML) and MLP. The PRML detector is used to reduce ISI and ITI and the MLP is utilized to improve the system performance. After data is passed through BPMR channel, the proposed detection process is as follows. (1) First, we apply the MLP comprised of three hidden layer. The MLP output are fed to equalizer and SOVA and exploited as extrinsic information. (2) The received data with scaled down MLP output are equalized by 2D minimum mean square error (MMSE) equalizer. (3) When the branch metric of Viterbi detector is calculated, the equalizer output are used to reduce the impact of ISI, and the scaled down MLP output are used to reduce the impact of ITI. Then, the Viterbi output are sent to the MLP. (4) In iterative detection process, the MLP delivers the output only to the Viterbi detector, and the Viterbi detector delivers the output only to the MLP. And, Viterbi detector outputs the estimated data. Fig. 2 illustrates the BER performance of the proposed detection scheme according to the number of iteration at 3 terabit per square inch. At the BER of 10-4, the performance of proposed scheme at 1st iteration shows best performance.References: [1] H. J. Richter et al, IEEE Trans. Magn., Vol. 42, pp. 2255-2260, (2006) [2] W. Chang and J. R. Cruz, IEEE Trans. Magn., Vol. 46, pp. 3899-3908, (2010)

MMM 2020

Iterative Detection with Multilayer Perceptron for Bit-Patterned Media Recording
