In this paper we present a new scheduling model for resilient real-time mixed trust systems. This model extends the previous Real-Time Mixed-Trust Computing framework RT-MTC to support degradation modes. Management of these modes has been identified in industrial documents as a key requirement for deploying trusted autonomous vehicles for safe autonomy. RT-MTC uses verified components (known as enforcers) to guarantee that the output of a system is safe by replacing it with a verified safe one if this output is deemed unsafe or is not produced on time. In this paper we extend RT-MTC and develop a scheduling model that uses the digraph scheduling model as a baseline but extends it in four critical ways: (1) it creates extensions for the mixed-preemptive scheduling required by RT-MTC, (2) it enables priority bands in order to separate trusted and untrusted components, (3) it uses these bands in order to calculate intermediate deadlines used by the RT-MTC framework for the scheduling of the trusted components, and (4) it defines system mode semantics to obtain two desirable properties of the new schedulability analysis: low pessimism and low time-complexity. This paper evaluates the new schedulability algorithm and shows that it is efficient in that it only needs to analyze one transition at a time. The new model supports the construction of a resilient autonomous system with provable guarantees protected by verified enforcers within the RT-MTC framework and, more importantly, preserves these guarantees even across failure-triggered mode changes.

IEEE RTSS 2021

Resilient Mixed-Trust Scheduling

job shop scheduling

analytical models

computational modeling

degradation

semantics

processor scheduling

real-time systems

 **RTSS 2021** has successfully concluded. Hope you have enjoyed it, and look forward to seeing you next year in person.
    Announcement for the Awards:
 * Best Paper Award goes to: Monte Carlo Response-Time Analysis, Sergey Bozhko, Georg von der Brüggen, and Björn Brandenburg
 * Best Student Paper Award goes to: Automatic Energy-Hotspot Detection and Elimination in Real-Time Deeply Embedded Systems, Mohsen Shekarisaz, Lothar Thiele, and Mehdi Kargahi.
 * Best Solution Award for Industry Session goes to: Toward Real-Time Guaranteed Scheduling for Autonomous Driving Systems. Jinghao Sun, Tianyi Wang, Kailu Duan, Bin Lu, Jiankang Ren, Zhishan Guo, and Guozhen Tan.



The IEEE Real-Time Systems Symposium (RTSS) is the premier conference in the field of real-time systems, and is a venue for researchers and practitioners to showcase innovations covering all aspects of real-time systems, including theory, design, analysis, implementation, evaluation, and experience.

technical paper

Deep neural networks (DNNs) have shown remark- able success in various machine-learning (ML) tasks useful for many safety-critical, real-time embedded systems. The foremost design goal for enabling DNN execution on real-time embedded systems is to provide worst-case timing guarantees with limited computing resources. Yet, the state-of-the-art ML frameworks hardly leverage heterogeneous computing resources (i.e., CPU, GPU) to improve the schedulability of real-time DNN tasks due to several factors, which include a coarse-grained resource allocation model (one-resource-per-task), the asymmetric nature of DNN execution on CPU and GPU, and lack of schedulability- aware CPU/GPU allocation scheme. This paper presents, to the best of our knowledge, the first study of addressing the above three major barriers and examining their cooperative effect on schedulability improvement. In this paper, we propose LaLaRAND, a real-time layer-level DNN scheduling framework, that enables flexible CPU/GPU scheduling of individual DNN layers by tightly coupling CPU-friendly quantization with fine-grained CPU/GPU allocation schemes (one-resource-per-layer) while mitigating ac- curacy loss without compromising timing guarantees. We have implemented and evaluated LaLaRAND on top of the state-of-the- art ML framework to demonstrate its effectiveness in making more DNN task sets schedulable by 56% and 80% over an existing approach and a baseline (vanilla PyTorch), respectively, with only up to -0.4% of performance (inference accuracy) difference.

LaLaRAND: Flexible Layer-by-Layer CPU/GPU Scheduling for Real-Time DNN Task

Thermal awareness is increasingly important for real-time systems deployed in harsh environments. As high chip temperature can cause frequency throttling or shutdown of processor cores at unexpected times, many real-time scheduling techniques have been developed to ensure continuous, fail-safe operation of safety-critical tasks with stringent timing constraints. However, their practical use remains largely limited due to the fact that it is extremely difficult to obtain a precise thermal model of commercial processors without using special measurement instruments or access to proprietary information, such as the power traces of micro-architectural units and detailed floorplans. In this paper, we propose a data-driven structured thermal modeling scheme that is directly applicable to commercial off-theshelf multi-core processors used in real-time embedded systems. By using a small number of thermal profiles obtained from onchip temperature sensors, our scheme can accurately predict the processor operating temperature under dynamic real-time workloads at various CPU frequencies and ambient conditions. The thermal model derived from our scheme is fast to converge and robust against different sources of errors. Our scheme is non-intrusive, meaning that it does not require changes to the software code or the hardware packaging of the target system. Furthermore, our scheme can estimate the relative power consumption of the processor for a given workload and clock frequency level. Experimental results from a multi-core ARM platform indicate that our scheme estimates the operating temperature with a maximum error of 2.5% while the latest prior work results in 23% error. This highly accurate modeling enables us to obtain the maximum achievable processor utilization that does not cause a thermal safety violation.

Data-Driven Structured Thermal Modeling for COTS Multi-Core Processors

The modeling and analysis of real-time applications focus on the worst-case scenario because of their strict timing requirements. However, many real-time embedded systems in- clude critical applications requiring not only timing constraints but also other system limitations, such as energy consumption. In this paper, we study the energy-aware real-time scheduling of Directed Acyclic Graph (DAG) tasks. We integrate the Dynamic Power Management (DPM) policy to reduce the Worst-Case Energy Consumption (WCEC), which is an essential requirement for energy-constrained systems. Besides, we extend our analysis with tasks’ probabilistic information to improve the Average- Case Energy Consumption (ACEC), which is, instead, a common non-functional requirement of embedded systems. To verify the benefits of our approach in terms of reduced energy consumption, we finally conduct an extensive simulation, followed by an experimental study on an Odroid-H2 board. Compared to the state-of-the-art solution, our approach is able to reduce the power consumption up to 32.1%.

A Multi-Level DPM Approach for Real-Time DAG Tasks in Heterogeneous Processors

Real-time systems increasingly use multicore processors in order to satisfy thermal, power, and computational requirements. To exploit the architectural parallelism offered by the multicore processors, parallel task models, scheduling algorithms and response-time analyses with respect to real-time constraints have to be provided. In this paper, we propose a reservation-based scheduling algorithm for sporadic constrained-deadline parallel conditional DAG tasks with probabilistic execution behaviour for applications that can tolerate bounded number of deadline misses and bounded tardiness. We devise design rules and analyses to guarantee bounded tardiness for a specified bounded probability for k-consecutive deadline misses without enforcing late jobs to be immediately aborted.

Response-Time Analysis and Optimization for Probabilistic Conditional Parallel DAG Tasks

Robots are commonly subject to real-time constraints. To ensure that such constraints are met, recent work has analyzed the response times of processing chains under ROS 2, a popular robotics framework. However, prior work supports only scalar worst-case execution time bounds and does not exploit that the ROS 2 scheduling mechanism is starvation-free. This paper proposes a novel response-time analysis for ROS 2 processing chains that accounts for both the high execution-time variance typically encountered in robotics workloads and the starvation freedom of the default ROS 2 callback scheduler. Experimental results from both synthetic callback graphs and a real ROS 2 workload empirically show the proposed analysis to be much more accurate (often by a factor of 2x or more).

A ROS 2 Response-Time Analysis Exploiting Starvation Freedom and Execution-Time Variance

This paper presents a task synchronization mechanism, called co-runner locking, to address the timing interference problem in multi-core real-time systems. It prevents certain subsets of tasks from executing simultaneously on different cores in order to avoid large performance penalties from inter-core interference. We provide the general properties of the co-runner locking mechanism and discuss the runtime control policies that determine the execution order of tasks in a co-runner locking relationship. For schedulability analysis, we derive a response-time test that upper-bounds the delay from co-runner locking and the slowdown imposed by permitted co-runners by combining two new analytic approaches: job-oriented and load-oriented. In evaluation, we demonstrate that the co-runner locking mechanism is an effective alternative to address the “one out-of-m” problem and brings about a significant improvement in real-time taskset schedulability.

Addressing Multi-Core Timing Interference using Co-Runner Locking

Determining a soft or firm real-time task’s probabilistic worst-case response time is a central goal when quantifying and bounding the probability of deadline misses, but current approaches are either (i) fast, but coarse-grained analytical bounds without precision guarantees, (ii) based on convolution and suffer from high space and time complexity, or (iii) combine convolution with resampling techniques that accrue pessimism in an uncontrolled manner. As a new alternative, this paper provides the first probabilistic response-time analysis method based on Monte Carlo simulation, which provides a controlled trade-off between analysis runtime, the desired degree of accuracy, and the permissible probability of a misestimate. An evaluation shows the proposed Monte Carlo analysis to routinely provide more accurate worst-case deadline failure probability (WCDFP) estimates than prior approaches, especially when considering large task sets (where prior methods struggle). In particular, it is shown to scale to workloads with up to 500 tasks while achieving one to three orders of magnitude better precision than analytical or convolution-based approaches (given an equivalent time budget).

Monte Carlo Response-Time Analysis

Time synchronization of devices in Internet-of- Things (IoT) networks is one of the challenging problems and a pre-requisite for the design of low-latency applications. Although many existing solutions have tried to address this problem, almost all solutions assume all the devices (nodes) in the network are faultless. Furthermore, these solutions exchange a large number of messages to achieve synchronization, leading to significant communication and energy overhead. To address these shortcomings, we propose C-sync, a clustering-based decentralized time synchronization protocol that provides resilience against several types of faults with energy-efficient communication. Csync achieves scalability by introducing multiple reference nodes in the network that restrict the maximum number of hops any node can have to its time source. The protocol is designed with a modular structure on the Contiki platform to allow application transitions. We evaluate C-sync on a real testbed that comprises over 40 Tmote Sky hardware nodes distributed across different levels in a building and show through experiments the fault resilience, energy efficiency, and scalability of the protocol. Csync detects and isolates faults to a cluster and recovers quickly. The evaluation makes a qualitative comparison with state-ofthe- art protocols and a quantitative comparison with a class of decentralized protocols (derived from GTSP) that provide synchronization with no/limited fault-tolerance. Results also show a reduction of 56.12% and 75.75% in power consumption in the worst-case and best-case scenarios, respectively, compared to GTSP, while achieving similar accuracy.

Cluster-based Network Time Synchronization for Resilience with Energy Efficiency

We present a middleware-based protocol that reliably synchronizes large samples consisting of multiple frames efficiently and within application level QoS requirements over a lossy wireless channel. The protocol uses a custom retransmission scheme, exploiting the latency requirements on sample level for frame level scheduling. It can be integrated into the popular DDS middleware. We investigate some technical limits of such a protocol and compare it to existing error protocols in the software stack and in the wireless protocol and combinations thereof. The comparison is based on an Omnet++ simulation using an established wireless channel error model. For evaluation, we take a use case from automated valet parking where infrastructure data provided via a wireless link augments in-vehicle sensor data. The use case respects the related safety requirements. Results show that the application awareness of the presented protocol, significantly improves service availability by transmitting data efficiently in time even under higher frame error rates.

A middleware protocol for time-critical wireless communication of large data samples

The Clock Constraint Specification Language (CCSL) has become popular for modeling and analyzing timing behaviors of real-time embedded systems. However, it is dicult for requirement engineers to accurately figure out CCSL specifications from natural language-based requirement descriptions. This is mainly because: i) most requirement engineers lack expertise in formal modeling; and ii) few existing tools can be used to facilitate the generation of CCSL specifications. To address these issues, this paper presents a novel approach that combines the merits of both Reinforcement Learning (RL) and deductive techniques in logical reasoning for ecient co-synthesis of CCSL specifications. Specifically, our method leverages RL to enumerate all the feasible solutions to fill the holes of incomplete specifications and deductive techniques to judge the quality of each trial. Our proposed deductive mechanisms are useful for not only pruning enumeration space, but also guiding the enumeration process to reach an optimal solution quickly. Comprehensive experimental results on both well-known benchmarks and complex industrial examples demonstrate the performance and scalability of our method. Compared with the state-of-theart, our approach can drastically reduce the synthesis time by several orders of magnitude while the accuracy of synthesis can be guaranteed.
