Magnetization switching plays a central role in the field of magnetism-based devices. A concrete example is the case of magnetic textures which play the role of carriers of information. A precise control of their mobility becomes crucial for potential applications such as racetrack memories [1], sensors [2], and logic-devices [3]. Both ferromagnets (FM) and antiferromagnets (AFM) can host multiple types of these textures. While FM have been investigated in depth, only recently a mechanism to excite AFM was proposed based on the fact that there are certain materials in which their magnetic sublattices form inversion partners, being possible to generate a current-induced Néel spin-orbit (SO) field [4]. With this objective in mind, we have evaluated the dynamics of a one-dimensional Néel-like DW in an embedded FM layer of the metallic layered Mn2Au excited through the Néel SO field. To do this, we have combined atomistic spin dynamics simulations of the real crystalline structure together with an analytical model that combines the Lagrangian formalism with the collective coordinates approach. When theoretically formalizing the problem, complications arise to define an unique Néel order parameter due to the complexity of the system. To avoid this, we have introduced a pair of staggered AFM-coupled Néel vectors. Taking this into account, we have evaluated three consecutive correlated SO field-based regions: one of acceleration driven by a ramped stimulus, another of steady-steady at constant speed, and a friction-driven regime in the absence of external fields. Traces of the inertial dynamics of the magnetic texture and a great stability of the DW even at speeds very close to the maximum magnon group velocity of the medium have been observed. On the other hand, it has been possible to predict the distance traveled by the magnetic soliton in its friction-driven motion, which is of the order of 5-10 times greater than the DW width at rest for moderate fields of 10-60 mT. This opens up the possibility of exploiting the phenomenon of inertia to reduce the power consumption in those technological applications such as racetrack memories in which the position of the magnetic texture needs to be precisely determined.References: [1] S. S. Parkin, M. Hayashi, and L. Thomas, Science, Vol. 320, p. 190-194 (2008) [2] R. Mattheis, S. Glathe, M. Diegel, et al., Journal of Applied Physics, Vol. 111, p. 113920 (2012) [3] P. Wadley, B. Howells, J. Zelezný, et al., Science, Vol. 351, p. 587-590 (2016) [4] J. Zelezný, H. Gao, K. Výborný, et al., Physical Review Letters, Vol. 113, p. 157201 (2014)

MMM 2020

Inertial Domain Wall Motion Driven by Staggered Spin-Orbit Fields in Layered Antiferromagnets
